In the era of big data and AI, companies are continually seeking ways to use these technologies to gain a competitive edge. One of the hottest areas in AI right now is generative AI, and for good reason. Generative AI offers powerful solutions that push the boundaries of what’s possible in terms of creativity and innovation. At the core of these cutting-edge solutions lies a foundation model (FM), a highly advanced machine learning model that is pre-trained on vast amounts of data. Many of these foundation models have shown remarkable capability in understanding and generating human-like text, making them a valuable tool for a variety of applications, from content creation to customer support automation.

However, these models are not without their challenges. They are exceptionally large and require large amounts of data and computational resources to train. Additionally, optimizing the training process and calibrating the parameters can be a complex and iterative process, requiring expertise and careful experimentation. These can be barriers for many organizations looking to build their own foundation models. To overcome this challenge, many customers are considering to fine-tune existing foundation models. This is a popular technique to adjust a small portion of model parameters for specific applications while still preserving the knowledge already encoded in the model. It allows organizations to use the power of these models while reducing the resources required to customize to a specific domain or task.

There are two primary approaches to fine-tuning foundation models: traditional fine-tuning and parameter-efficient fine-tuning. Traditional fine-tuning involves updating all the parameters of the pre-trained model for a specific downstream task. On the other hand, parameter-efficient fine-tuning includes a variety of techniques that allow for customization of a model without updating all the original model parameters. One such technique is called Low-rank Adaptation (LoRA). It involves adding small, task-specific modules to the pre-trained model and training them while keeping the rest of the parameters fixed as shown in the following image.

Source: Generative AI on AWS (O’Reilly, 2023)

LoRA has gained popularity recently for several reasons. It offers faster training, reduced memory requirements, and the ability to reuse pre-trained models for multiple downstream tasks. More importantly, the base model and adapter can be stored separately and combined at any time, making it easier to store, distribute, and share fine-tuned versions. However, this introduces a new challenge: how to properly manage these new types of fine-tuned models. Should you combine the base model and adapter or keep them separate? In this post, we walk through best practices for managing LoRA fine-tuned models on Amazon SageMaker to address this emerging question.

Working with FMs on SageMaker Model Registry

In this post, we walk through an end-to-end example of fine-tuning the Llama2 large language model (LLM) using the QLoRA method. QLoRA combines the benefits of parameter efficient fine-tuning with 4-bit/8-bit quantization to further reduce the resources required to fine-tune a FM to a specific task or use case. For this, we will use the pre-trained 7 billion parameter Llama2 model and fine-tune it on the databricks-dolly-15k dataset. LLMs like Llama2 have billions of parameters and are pretrained on massive text datasets. Fine-tuning adapts an LLM to a downstream task using a smaller dataset. However, fine-tuning large models is computationally expensive. This is why we will use the QLoRA method to quantize the weights during finetuning to reduce this computation cost.

In our examples, you will find two notebooks (llm-finetune-combined-with-registry.ipynb and llm-finetune-separate-with-registry.ipynb). Each works through a different way to handle LoRA fine-tuned models as illustrated in the following diagram:

1. First, we download the pre-trained Llama2 model with 7 billion parameters using SageMaker Studio Notebooks. LLMs, like Llama2, have shown state-of-the-art performance on natural language processing (NLP) tasks when fine-tuned on domain-specific data.
2. Next, we fine-tune Llama2 on the databricks-dolly-15k dataset using the QLoRA method. QLoRA reduces the computational cost of fine-tuning by quantizing model weights.
3. During fine-tuning, we integrate SageMaker Experiments Plus with the Transformers API to automatically log metrics like gradient, loss, etc.
4. We then version the fine-tuned Llama2 model in SageMaker Model Registry using two approaches:
   1. Storing the full model
   2. Storing the adapter and base model separately.
5. Finally, we host the fine-tuned Llama2 models using Deep Java Library (DJL) Serving on a SageMaker Real-time endpoint.

In the following sections, we will dive deeper into each of these steps, to demonstrate the flexibility of SageMaker for different LLM workflows and how these features can help improve the operations of your models.

Prerequisites

Complete the following prerequisites to start experimenting with the code.

• Create a SageMaker Studio Domain: Amazon SageMaker Studio, specifically Studio Notebooks, is used to kick off the Llama2 fine-tuning task then register and view models within SageMaker Model Registry. SageMaker Experiments is also used to view and compare Llama2 fine-tuning job logs (training loss/test loss/etc.).
• Create an Amazon Simple Storage Service (S3) bucket: Access to an S3 bucket to store training artifacts and model weights is required. For instructions, refer to Creating a bucket. The sample code used for this post will use the SageMaker default S3 bucket but you can customize it to use any relevant S3 bucket.
• Set up Model Collections (IAM permissions): Update your SageMaker Execution Role with permissions to resource-groups as listed under Model Registry Collections Developer Guide to implement Model Registry grouping using Model Collections.
• Accept the Terms & Conditions for Llama2: You will need to accept the end-user license agreement and acceptable use policy for using the Llama2 foundation model.

The examples are available in the GitHub repository. The notebook files are tested using Studio notebooks running on PyTorch 2.0.0 Python 3.10 GPU Optimized kernel and ml.g4dn.xlarge instance type.

Experiments plus callback integration

Amazon SageMaker Experiments lets you organize, track, compare and evaluate machine learning (ML) experiments and model versions from any integrated development environment (IDE), including local Jupyter Notebooks, using the SageMaker Python SDK or boto3. It provides the flexibility to log your model metrics, parameters, files, artifacts, plot charts from the different metrics, capture various metadata, search through them and support model reproducibility. Data scientists can quickly compare the performance and hyperparameters for model evaluation through visual charts and tables. They can also use SageMaker Experiments to download the created charts and share the model evaluation with their stakeholders.

Training LLMs can be a slow, expensive, and iterative process. It is very important for a user to track LLM experimentation at scale to prevent an inconsistent model tuning experience. HuggingFace Transformer APIs allow users to track metrics during training tasks through Callbacks. Callbacks are “read only” pieces of code that can customize the behavior of the training loop in the PyTorch Trainer that can inspect the training loop state for progress reporting, logging on TensorBoard or SageMaker Experiments Plus via custom logic (which is included as a part of this codebase).

You can import the SageMaker Experiments callback code included in this post’s code repository as shown in the following code block:

# imports a custom implementation of Experiments Callback
from smexperiments_callback import SageMakerExperimentsCallback
...
...
# Create Trainer instance with SageMaker experiments callback
trainer = Trainer(
    model=model,
    args=training_args,
    train_dataset=train_dataset,
    eval_dataset=validation_dataset,
    data_collator=default_data_collator,
    callbacks=[SageMakerExperimentsCallback] # Add our Experiments Plus Callback function
)

This callback will automatically log the following information into SageMaker Experiments as a part of the training run:

• Training Parameters and Hyper-Parameters
• Model Training and Validation loss at Step, Epoch and Final
• Model Input and Output artifacts (training dataset, validation dataset, model output location, training debugger and more)

The following graph shows examples of the charts you can display by using that information.

This allows you to compare multiple runs easily using the Analyze feature of SageMaker Experiments. You can select the experiment runs you want to compare, and they will automatically populate comparison graphs.

Register fine-tuned models to Model Registry Collections

Model Registry Collections is a feature of SageMaker Model Registry that allows you to group registered models that are related to each other and organize them in hierarchies to improve model discoverability at scale. We will use Model Registry Collections to keep track of the base model and fine-tuned variants.

Full Model Copy method

The first method combines the base model and LoRA adapter and saves the full fine-tuned model. The following code illustrates the model merging process and saves the combined model using model.save_pretrained().

if args.merge_weights:

    trainer.model.save_pretrained(temp_dir, safe_serialization=False)
    # clear memory
    del model
    del trainer
    torch.cuda.empty_cache()

    from peft import AutoPeftModelForCausalLM

    # load PEFT model in fp16
    model = AutoPeftModelForCausalLM.from_pretrained(
        temp_dir,
        low_cpu_mem_usage=True,
        torch_dtype=torch.float16,
    )
    # Merge LoRA and base model and save
    model = model.merge_and_unload()
    model.save_pretrained(
        args.sm_model_dir, safe_serialization=True, max_shard_size="2GB"
    )

Combining the LoRA adapter and base model into a single model artifact after fine-tuning has advantages and disadvantages. The combined model is self-contained and can be independently managed and deployed without needing the original base model. The model can be tracked as its own entity with a version name reflecting the base model and fine-tuning data. We can adopt a nomenclature using the base_model_name + fine-tuned dataset_name to organize the model groups. Optionally, model collections could associate the original and fine-tuned models, but this may not be necessary since the combined model is independent.  The following code snippet shows you how to register the fine-tuned model.

# Model Package Group Vars
ft_package_group_name = f"{model_id.replace('/', '--')}-{dataset_name}"
ft_package_group_desc = "QLoRA for model Mikael110/llama-2-7b-{dataset_name}-fp16"
...
...
...
model_package_group_input_dict = {
    "ModelPackageGroupName" : ft_package_group_name,
    "ModelPackageGroupDescription" : ft_package_group_desc,
    "Tags": ft_tags
}
create_model_pacakge_group_response = sm_client.create_model_package_group(
**model_package_group_input_dict
)

You can use the training estimator to register the model into Model Registry.

inference_image_uri = sagemaker.image_uris.retrieve(
    "djl-deepspeed", region=region, version="0.23.0"
)
print(f"Image going to be used is ---- > {inference_image_uri}")

model_package = huggingface_estimator.register(
    content_types=["application/json"],
    response_types=["application/json"],
    inference_instances=[
        "ml.p2.16xlarge",
...
...
...
    ],
    image_uri = inference_image_uri,
    customer_metadata_properties = {"training-image-uri": huggingface_estimator.training_image_uri()},  #Store the training image url
    model_package_group_name=ft_model_pkg_group_name,
    approval_status="Approved"
)

model_package_arn = model_package.model_package_arn
print("Model Package ARN : ", model_package_arn)

From Model Registry, you can retrieve the model package and deploy that model directly.

endpoint_name = f"{name_from_base(model_group_for_base)}-endpoint"

model_package.deploy(
    initial_instance_count=1,
    instance_type="ml.g5.12xlarge",
    endpoint_name=endpoint_name
)

However, there are drawbacks to this approach. Combining the models leads to storage inefficiency and redundancy since the base model is duplicated in each fine-tuned version. As model size and the number of fine-tuned models increase, this exponentially inflates storage needs. Taking the llama2 7b model as an example, the base model is approximately 13 GB and the fine-tuned model is 13.6 GB. 96% percent of the model needs to be duplicated after each fine tuning. Additionally, distributing and sharing very large model files also becomes more difficult and presents operational challenges as file transfer and management cost increases with increasing model size and fine-tune jobs.

Separate adapter and base method

The second method focuses on separation of base weights and adapter weights by saving them as separate model components and loading them sequentially at runtime.

    ..
    ..
    ..
    else:
        # save finetuned LoRA model and then the tokenizer for inference
        trainer.model.save_pretrained(
            args.sm_model_dir,
            safe_serialization=True
        )
    tokenizer.save_pretrained(
        args.sm_model_dir
    )

Saving base and adapter weights has advantages and disadvantages, similar to the Full Model Copy method. One advantage is that it can save storage space. The base weights, which are the largest component of a fine-tuned model, are only saved once and can be reused with other adapter weights that are tuned for different tasks. For example, the base weights of Llama2-7B are about 13 GB, but each fine-tuning task only needs to store about 0.6 GB of adapter weights, which is a 95% space savings. Another advantage is that base weights can be managed separately from adapter weights using a base weights only model registry. This can be useful for SageMaker domains that are running in a VPC only mode without an internet gateway, since the base weights can be accessed without having to go through the internet.

Create Model Package Group for base weights

### Create Model Package Group
base_package_group_name = model_id.replace('/', '--')
base_package_group_desc = "Source: https://huggingface.co/Mikael110/llama-2-7b-guanaco-fp16"
...
...
...
model_package_group_input_dict = {
    "ModelPackageGroupName" : base_package_group_name,
    "ModelPackageGroupDescription" : base_package_group_desc,
    "Tags": base_tags
}
create_model_pacakge_group_response = sm_client.create_model_package_group(
**model_package_group_input_dict
)

>>>
Created ModelPackageGroup Arn : arn:aws:sagemaker:us-west-2:376678947624:model-package-group/Mikael110--llama-2-7b-guanaco-fp16
...
...
...

### Register Base Model Weights
from sagemaker.huggingface import HuggingFaceModel

# create Hugging Face Model Class
huggingface_model = HuggingFaceModel(
    transformers_version='4.28',
    pytorch_version='2.0',
    py_version='py310',
    model_data=model_data_uri, # this is an S3 path to your base weights as *.tar.gz
    role=role,
)

_response = huggingface_model.register(
    content_types=["application/json"],
    response_types=["application/json"],
    inference_instances=[
    "ml.p2.16xlarge",
    ...
    ],
    transform_instances=[
    "ml.p2.16xlarge",
    ...
    ],
    model_package_group_name=base_model_pkg_group_name,
    approval_status="Approved"
 )

Create Model Package Group for QLoRA weights

The following code shows how to tag QLoRA weights with the dataset/task type and register fine-tuned delta weights into a separate model registry and track the delta weights separately.

### Create Model Package Group for delta weights
ft_package_group_name = f"{model_id.replace('/', '--')}-finetuned-sql"
ft_package_group_desc = "QLoRA for model Mikael110/llama-2-7b-guanaco-fp16"
ft_tags = [
    {
    "Key": "modelType",
    "Value": "QLoRAModel"
    },
    {
    "Key": "fineTuned",
    "Value": "True"
    },
    {
    "Key": "sourceDataset",
    "Value": f"{dataset_name}"
    }
]
model_package_group_input_dict = {
    "ModelPackageGroupName" : ft_package_group_name,
    "ModelPackageGroupDescription" : ft_package_group_desc,
    "Tags": ft_tags
}
create_model_pacakge_group_response = sm_client.create_model_package_group(
**model_package_group_input_dict
)
print(f'Created ModelPackageGroup Arn : {create_model_pacakge_group_response["ModelPackageGroupArn"]}')
ft_model_pkg_group_name = create_model_pacakge_group_response["ModelPackageGroupArn"]

>>>
Created ModelPackageGroup Arn : arn:aws:sagemaker:us-east-1:811828458885:model-package-group/mikael110--llama-2-7b-guanaco-fp16-finetuned-sql

...
...
...

### Register Delta Weights QLoRA Model Weights
huggingface_model = HuggingFaceModel(
    transformers_version='4.28',
    pytorch_version='2.0',
    py_version='py310',
    model_data="s3://sagemaker-us-east-1-811828458885/huggingface-qlora-2308180454/output/model.tar.gz", OR #huggingface_estimator.model_data
    role=role,
)

_response = huggingface_model.register(
    content_types=["application/json"],
    response_types=["application/json"],
    inference_instances=[
    "ml.p2.16xlarge",
    ...
    ],
    transform_instances=[
    "ml.p2.16xlarge",
    ...
    ],
    model_package_group_name=ft_model_pkg_group_name,
    approval_status="Approved"
)

>>>
Model collection creation status: {'added_groups': ['arn:aws:sagemaker:us-east-1:811828458885:model-package-group/mikael110--llama-2-7b-guanaco-fp16-finetuned-sql'], 'failure': []}

The following snippet shows a view from the Model Registry where the models are split into base and fine-tuned weights.

Managing models, datasets, and tasks for hyper-personalized LLMs can quickly become overwhelming. SageMaker Model Registry Collections can help you group related models together and organize them in a hierarchy to improve model discoverability. This makes it easier to track the relationships between base weights, adapter weights, and fine-tuning task datasets. You can also create complex relationships and linkages between models.

Create a new Collection and add your base model weights to this Collection

# create model collection
base_collection = model_collector.create(
    collection_name=model_group_for_base # ex: "Website_Customer_QnA_Bot_Model"
)

# Add the base weights at first level of model collections as all future models
# are going to be tuned from the base weights
_response = model_collector.add_model_groups(
    collection_name=base_collection["Arn"],
    model_groups=[base_model_pkg_group_name]
)
print(f"Model collection creation status: {_response}")

>>>
Model collection creation status: {'added_groups': ['arn:aws:sagemaker:us-west-2:376678947624:model-package-group/Mikael110--llama-2-7b-guanaco-fp16'], 'failure': []}

Link all your Fine-Tuned LoRA Adapter Delta Weights to this collection by task and/or dataset

# create model collection for finetuned and link it back to the base
finetuned_collection = model_collector.create(
    collection_name=model_group_for_finetune,
    parent_collection_name=model_group_for_base
)

# add finetuned model package group to the new finetuned collection
_response = model_collector.add_model_groups(
    collection_name=model_group_for_finetune,
    model_groups=[ft_model_pkg_group_name]
)
print(f"Model collection creation status: {_response}")

>>>
Model collection creation status: {'added_groups': ['arn:aws:sagemaker:us-east-1:811828458885:model-package-group/mikael110--llama-2-7b-guanaco-fp16-finetuned-sql'], 'failure': []}

This will result in a collection hierarchy which are linked by model/task type and the dataset used to fine tune the base model.

This method of separating the base and adapter models has some drawbacks. One drawback is complexity in deploying the model. Because there are two separate model artifacts, you need additional steps to repackage the model instead of deploy directly from Model Registry. In the following code example, download and repack the latest version of the base model first.

!aws s3 cp {base_model_package.model_data} .

!tar -xvf {model_tar_filename} -C ./deepspeed/

!mv ./deepspeed/{model_id} ./deepspeed/base

!rm -rf ./deepspeed/{model_id}

Then download and repack the latest fine-tuned LoRA adapter weights.

!aws s3 cp {LoRA_package.model_data} .

!mkdir -p ./deepspeed/lora/

!tar -xzf model.tar.gz -C ./deepspeed/lora/

Since you will be using DJL serving with deepspeed to host the model, your inference directory should look like the following.

deepspeed
    |-serving.properties
    |-requirements.txt
    |-model.py
    |-base/
        |-...
    |-lora/
        |-...

Finally, package the custom inference code, base model, and LoRA adaptor in a single .tar.gz file for deployment.

!rm -f model.tar.gz
!tar czvf model.tar.gz -C deepspeed .
s3_code_artifact_deepspeed = sagemaker_session.upload_data("model.tar.gz", default_bucket, f"{s3_key_prefix}/inference")
print(f"S3 Code or Model tar for deepspeed uploaded to --- > {s3_code_artifact_deepspeed}")

Clean up

Clean up your resources by following the instructions in the cleanup section of the notebook. Refer to Amazon SageMaker Pricing for details on the cost of the inference instances.

Conclusion

This post walked you through best practices for managing LoRA fine-tuned models on Amazon SageMaker. We covered two main methods: combining the base and adapter weights into one self-contained model, and separating the base and adapter weights. Both approaches have tradeoffs, but separating weights helps optimize storage and enables advanced model management techniques like SageMaker Model Registry Collections. This allows you to build hierarchies and relationships between models to improve organization and discoverability. We encourage you to try the sample code on GitHub repository to experiment with these methods yourself. As generative AI progresses rapidly, following model management best practices will help you track experiments, find the right model for your task, and manage specialized LLMs efficiently at scale.

References

• Next generation Amazon SageMaker Experiments
• HuggingFace Callbacks

About the authors

James Wu is a Senior AI/ML Specialist Solution Architect at AWS. helping customers design and build AI/ML solutions. James’s work covers a wide range of ML use cases, with a primary interest in computer vision, deep learning, and scaling ML across the enterprise. Prior to joining AWS, James was an architect, developer, and technology leader for over 10 years, including 6 years in engineering and 4 years in marketing & advertising industries.

Pranav Murthy is an AI/ML Specialist Solutions Architect at AWS. He focuses on helping customers build, train, deploy and migrate machine learning (ML) workloads to SageMaker. He previously worked in the semiconductor industry developing large computer vision (CV) and natural language processing (NLP) models to improve semiconductor processes. In his free time, he enjoys playing chess and traveling.

Mecit Gungor is an AI/ML Specialist Solution Architect at AWS helping customers design and build AI/ML solutions at scale. He covers a wide range of AI/ML use cases for Telecommunication customers and currently focuses on Generative AI, LLMs, and training and inference optimization. He can often be found hiking in the wilderness or playing board games with his friends in his free time.

Shelbee Eigenbrode is a Principal AI and Machine Learning Specialist Solutions Architect at Amazon Web Services (AWS). She has been in technology for 24 years spanning multiple industries, technologies, and roles. She is currently focusing on combining her DevOps and ML background into the domain of MLOps to help customers deliver and manage ML workloads at scale. With over 35 patents granted across various technology domains, she has a passion for continuous innovation and using data to drive business outcomes. Shelbee is a co-creator and instructor of the Practical Data Science specialization on Coursera. She is also the Co-Director of Women In Big Data (WiBD), Denver chapter. In her spare time, she likes to spend time with her family, friends, and overactive dogs.

Read More

At a basic level, Machine Learning (ML) technology learns from data to make predictions. Businesses use their data with an ML-powered personalization service to elevate their customer experience. This approach allows businesses to use data to derive actionable insights and help grow their revenue and brand loyalty.

Amazon Personalize accelerates your digital transformation with ML, making it easier to integrate personalized recommendations into existing websites, applications, email marketing systems, and more. Amazon Personalize enables developers to quickly implement a customized personalization engine, without requiring ML expertise. Amazon Personalize provisions the necessary infrastructure and manages the entire machine learning (ML) pipeline, including processing the data, identifying features, using the most appropriate algorithms, and training, optimizing, and hosting the models. You receive results through an API and pay only for what you use, with no minimum fees or upfront commitments.

The post Architecting near real-time personalized recommendations with Amazon Personalize shows how to architect near real-time personalized recommendations using Amazon Personalize and AWS purpose-built data services. In this post, we walk you through a reference implementation of a real-time personalized recommendation system using Amazon Personalize.

Solution overview

The real-time personalized recommendations solution is implemented using Amazon Personalize, Amazon Simple Storage Service (Amazon S3), Amazon Kinesis Data Streams, AWS Lambda, and Amazon API Gateway.

The architecture is implemented as follows:

1. Data preparation – Start by creating a dataset group, schemas, and datasets representing your items, interactions, and user data.
2. Train the model – After importing your data, select the recipe matching your use case, and then create a solution to train a model by creating a solution version. When your solution version is ready, you can create a campaign for your solution version.
3. Get near real-time recommendations – When you have a campaign, you can integrate calls to the campaign in your application. This is where calls to the GetRecommendations or GetPersonalizedRanking APIs are made to request near real-time recommendations from Amazon Personalize.

For more information, refer to Architecting near real-time personalized recommendations with Amazon Personalize.

The following diagram illustrates the solution architecture.

Implementation

We demonstrate this implementation with a use case about making real-time movie recommendations to an end user based on their interactions with the movie database over time.

The solution is implemented using the following steps:

1. Prerequisite (Data preparation)
2. Setup your development environment
3. Deploy the solution
4. Create a solution version
5. Create a campaign
6. Create an event tracker
7. Get recommendations
8. Ingest real-time interactions
9. Validate real-time recommendations
10. Cleanup

Prerequisites

Before you get started, make sure you have the following prerequisites:

• Prepare your training data – Prepare and upload the data to an S3 bucket using the instructions. For this particular use case, you will be uploading interactions data and items data. An interaction is an event that you record and then import as training data. Amazon Personalize generates recommendations primarily based on the interactions data you import into an Interactions dataset. You can record multiple event types, such as click, watch, or like. Although the model created by Amazon Personalize can suggest based on a user’s past interactions, the quality of these suggestions can be enhanced when the model possesses data about the associations among users or items . If a user has engaged with movies categorized as Drama in the item dataset, Amazon Personalize will suggest movies (items) with the same genre.
• Setup your development environment – Install the AWS Command Line Interface (AWS CLI).
• Configure CLI with your Amazon account – Configure the AWS CLI with your AWS account information.
• Install and bootstrap AWS Cloud Development Kit (AWS CDK)

Deploy the solution

To deploy the solution, do the following:

• Clone the repository to a new folder on your desktop.
• Deploy the stack to your AWS environment.

Create a solution version

A solution refers to the combination of an Amazon Personalize recipe, customized parameters, and one or more solution versions (trained models). When you deploy the CDK project in the previous step, a solution with a User-Personalization recipe is created for you automatically. A solution version refers to a trained machine learning model. Create a solution version for the implementation.

Create a campaign

A campaign deploys a solution version (trained model) with a provisioned transaction capacity for generating real-time recommendations. Create a campaign for the implementation.

Create an event tracker

Amazon Personalize can make recommendations based on real-time event data only, historical event data only, or both. Record real-time events to build out your interactions data and allow Amazon Personalize to learn from your user’s most recent activity. This keeps your data fresh and improves the relevance of Amazon Personalize recommendations. Before you can record events, you must create an event tracker. An event tracker directs new event data to the Interactions dataset in your dataset group. Create and event tracker for the implementation.

Get recommendations

In this use case, the interaction dataset is composed of movie IDs. Consequently, the recommendations presented to the user will consist of movie IDs that align most closely with their personal preferences, determined from their historical interactions. You can use the getRecommendations API to retrieve personalized recommendations for a user by sending its associated userID, the number of results for recommendations that you need for the user as well as the campaign ARN. You can find the campaign ARN in the Amazon Personalize console menu.

For example, the following request will retrieve 5 recommendations for the user whose userId is 429:

curl --location 'https://{your-api-id}.execute-api.{your-region}.amazonaws.com/prod/getRecommendations?campaignArn={campaignArn}&userId=429&numResults=5'

The response from the request will be:

{
	"$metadata": {
		"httpStatusCode": 200,
		"requestId": "7159c128-4e16-45a4-9d7e-cf19aa2256e8",
		"attempts": 1,
		"totalRetryDelay": 0
	},
	"itemList": [
	{
		"itemId": "596",
		"score": 0.0243044
	},
	{
		"itemId": "153",
		"score": 0.0151695
	},
	{
		"itemId": "16",
		"score": 0.013694
	},
	{
		"itemId": "261",
		"score": 0.013524
	},
	{
		"itemId": "34",
		"score": 0.0122294
	}
	],
	"recommendationId": "RID-1d-40c1-8d20-dfffbd7b0ac7-CID-06b10f"
}

The items returned by the API call are the movies that Amazon Personalize recommends to the user based on their historical interactions.

The score values provided in this context represent floating-point numbers that range between zero and 1.0. These values correspond to the current campaign and the associated recipes for this use case. They are determined based on the collective scores assigned to all items present in your comprehensive dataset.

Ingest real-time interactions

In the previous example, recommendations were obtained for the user with an ID of 429 based on their historical interactions with the movie database. For real-time recommendations, the user interactions with the items must be ingested into Amazon Personalize in real-time. These interactions are ingested into the recommendation system through the Amazon Personalize Event Tracker. The type of interaction, also called EventType, is given by the column of the same name in the interaction data dataset (EVENT_TYPE). In this example, the events can be of type “watch” or “click”, but you can have your own types of events according to the needs of your application.

In this example, the exposed API that generates the events of the users with the items receives the “interactions” parameter that corresponds to the number of events (interactions) of a user (UserId) with a single element (itemId) right now. The trackingId parameter can be found in the Amazon Personalize console and in the response of the creation of Event Tracker request.

This example shows a putEvent request: Generate 1 interactions of click type, with an item id of ‘185’ for the user id ‘429’, using the current timestamp. Note that in production, the ‘sentAt’ should be set to the time of the user’s interaction. In the following example, we set this to the point in time in epoch time format when we wrote the API request for this post. The events are sent to Amazon Kinesis Data Streams through an API Gateway which is why you need to send the stream-name and PartitionKey parameters.

curl --location 'https://iyxhva3ll6.execute-api.us-west-2.amazonaws.com/prod/data' --header 'Content-Type: application/json' --data '{ "stream-name": "my-stream","Data": {"userId" : "429", "interactions": 1, "itemId": "185", "trackingId" : "c90ac6d7-3d89-4abc-8a70-9b09c295cbcd", "eventType": "click", "sentAt":"1698711110"},"PartitionKey":"userId"}'

You will receive a confirmation response similar to the following:

{
	"Message": "Event sent successfully",
	"data": {
		"EncryptionType": "KMS",
		"SequenceNumber": "49..........1901314",
		"ShardId": "shardId-xxxxxxx"
	}
}

Validate real-time recommendations

Because the interaction dataset has been updated, the recommendations will be automatically updated to consider the new interactions. To validate the recommendations updated in real-time, you can call the getRecommendations API again for the same user id 429, and the result should be different from the previous one. The following results show a new recommendation with an id of 594 and the recommendations with the id’s of 16, 596, 153and 261 changed their scores. These items brought in new movie genre (‘Animation|Children|Drama|Fantasy|Musical’) the top 5 recommendations.

Request:

curl --location 'https://{your-api-id}.execute-api.{your-region}.amazonaws.com/prod/getRecommendations?campaignArn={campaignArn} &userId=429&numResults=5'

Response:

{
	"$metadata": {
		"httpStatusCode": 200,
		"requestId": "680f2be8-2e64-47d7-96f7-1c4aa9b9ac9d",
		"attempts": 1,
		"totalRetryDelay": 0
	},
	"itemList": [
	{
		"itemId": "596",
		"score": 0.0288085
	},
	{
		"itemId": "16",
		"score": 0.0134173
	},
	{
		"itemId": "594",
		"score": 0.0129357
	},
	{
		"itemId": "153",
		"score": 0.0129337
	},
	{
		"itemId": "261",
		"score": 0.0123728
	}
	],
	"recommendationId": "RID-dc-44f8-a327-482fb9e54921-CID-06b10f"
}

The response shows that the recommendation provided by Amazon Personalize was updated in real-time.

Clean up

To avoid unnecessary charges, clean up the solution implementation by using Cleaning up resources.

Conclusion

In this post, we showed you how to implement a real-time personalized recommendations system using Amazon Personalize. The interactions with Amazon Personalize to ingest real-time interactions and get recommendations were executed through a command line tool called curl but these API calls can be integrated into a business application and derive the same outcome.

To choose a new recipe for your use case, refer to Real-time personalization. To measure the impact of the recommendations made by Amazon Personalize, refer to Measuring impact of recommendations.

About the Authors

Cristian Marquez is a Senior Cloud Application Architect. He has vast experience designing, building, and delivering enterprise-level software, high load and distributed systems and cloud native applications. He has experience in backend and frontend programming languages, as well as system design and implementation of DevOps practices. He actively assists customers build and secure innovative cloud solutions, solving their business problems and achieving their business goals.

Anand Komandooru is a Senior Cloud Architect at AWS. He joined AWS Professional Services organization in 2021 and helps customers build cloud-native applications on AWS cloud. He has over 20 years of experience building software and his favorite Amazon leadership principle is “Leaders are right a lot.“

Read More

One of the most common applications of generative AI and large language models (LLMs) is answering questions based on a specific external knowledge corpus. Retrieval-Augmented Generation (RAG) is a popular technique for building question answering systems that use an external knowledge base. To learn more, refer to Build a powerful question answering bot with Amazon SageMaker, Amazon OpenSearch Service, Streamlit, and LangChain.

Traditional RAG systems often struggle to provide satisfactory answers when users ask vague or ambiguous questions without providing sufficient context. This leads to unhelpful responses like “I don’t know” or incorrect, made-up answers provided by an LLM. In this post, we demonstrate a solution to improve the quality of answers in such use cases over traditional RAG systems by introducing an interactive clarification component using LangChain.

The key idea is to enable the RAG system to engage in a conversational dialogue with the user when the initial question is unclear. By asking clarifying questions, prompting the user for more details, and incorporating the new contextual information, the RAG system can gather the necessary context to provide an accurate, helpful answer—even from an ambiguous initial user query.

Solution overview

To demonstrate our solution, we have set up an Amazon Kendra index (composed of the AWS online documentation for Amazon Kendra, Amazon Lex, and Amazon SageMaker), a LangChain agent with an Amazon Bedrock LLM, and a straightforward Streamlit user interface.

Prerequisites

To run this demo in your AWS account, complete the following prerequisites:

1. Clone the GitHub repository and follow the steps explained in the README.
2. Deploy an Amazon Kendra index in your AWS account. You can use the following AWS CloudFormation template to create a new index or use an already running index. Deploying a new index might add additional charges to your bill, therefore we recommend deleting it if you don’t longer need it. Note that the data within the index will be sent to the selected Amazon Bedrock foundation model (FM).
3. The LangChain agent relies on FMs available in Amazon Bedrock, but this can be adapted to any other LLM that LangChain supports.
4. To experiment with the sample front end shared with the code, you can use Amazon SageMaker Studio to run a local deployment of the Streamlit app. Note that running this demo will incur some additional costs.

Implement the solution

Traditional RAG agents are often designed as follows. The agent has access to a tool that is used to retrieve documents relevant to a user query. The retrieved documents are then inserted into the LLM prompt, so that the agent can provide an answer based on the retrieved document snippets.

In this post, we implement an agent that has access to KendraRetrievalTool and derives relevant documents from the Amazon Kendra index and provides the answer given the retrieved context:

# tool for Kendra retrieval

kendra_tool = Tool(
    name="KendraRetrievalTool",
    func=retrieval_qa_chain,
    description="Use this tool first to answer human questions. The input to this tool should be the question.",
)
# traditional RAG agent

traditional_agent = initialize_agent(
    agent=AgentType.ZERO_SHOT_REACT_DESCRIPTION,
    tools=[kendra_tool]
    llm=llm,
    early_stopping_method="generate",
    memory=conversational_memory,
)

# user question
answer = traditional_agent.run("How many GPUs does my EC2 instance have?")

Refer to the GitHub repo for the full implementation code. To learn more about traditional RAG use cases, refer to Question answering using Retrieval Augmented Generation with foundation models in Amazon SageMaker JumpStart.

Consider the following example. A user asks “How many GPUs does my EC2 instance have?” As shown in the following screenshot, the agent is looking for the answer using KendraRetrievalTool. However, the agent realizes it doesn’t know which Amazon Elastic Compute Cloud (Amazon EC2) instance type the user is referencing and therefore provides no helpful answer to the user, leading to a poor customer experience.

To address this problem, we define an additional custom tool called AskHumanTool and provide it to the agent. The tool instructs an LLM to read the user question and ask a follow-up question to the user if KendraRetrievalTool is not able to return a good answer. This implies that the agent will now have two tools at its disposal:

# tool for asking human
human_ask_tool = CustomAskHumanTool()

# RAG agent with two tools
improved_agent = initialize_agent(
    agent=AgentType.ZERO_SHOT_REACT_DESCRIPTION,
    tools=[kendra_tool, human_ask_tool],
    llm=llm,
    early_stopping_method="generate",
    memory=conversational_memory,
)

# user question
answer = improved_agent.run("How many GPUs does my EC2 instance have?")

This allows the agent to either refine the question or provide additional context that is needed to respond to the prompt. To guide the agent to use AskHumanTool for this purpose, we provide the following tool description to the LLM:

Use this tool if you don’t find an answer using the KendraRetrievalTool.
Ask the human to clarify the question or provide the missing information.
The input should be a question for the human.

As illustrated in the following screenshot, by using AskHumanTool, the agent is now identifying vague user questions and returning a follow-up question to the user asking to specify what EC2 instance type is being used.

After the user has specified the instance type, the agent is incorporating the additional answer into the context for the original question, before deriving the correct answer.

Note that the agent can now decide whether to use KendraRetrievalTool to retrieve the relevant documents or ask a clarifying question using AskHumanTool. The agent’s decision is based on whether it finds the document snippets inserted into the prompt sufficient to provide the final answer. This flexibility allows the RAG system to support different queries a user may submit, including both well-formulated and vague questions.

In our example, the full agent workflow is as follows:

1. The user makes a request to the RAG app, asking “How many GPUs does my EC2 instance have?”
2. The agent uses the LLM to decide what action to take: Find relevant information to answer the user’s request by calling the KendraRetrievalTool.
3. The agent retrieves information from the Amazon Kendra index using the tool. The snippets from the retrieved documents are inserted into the agent prompt.
4. The LLM (of the agent) derives that the retrieved documents from Amazon Kendra aren’t helpful or don’t contain enough context to provide an answer to the user’s request.
5. The agent uses AskHumanTool to formulate a follow-up question: “What is the specific EC2 instance type you are using? Knowing the instance type would help answer how many GPUs it has.” The user provides the answer “ml.g5.12xlarge,” and the agent calls KendraRetrievalTool again, but this time adding the EC2 instance type into the search query.
6. After running through Steps 2–4 again, the agent derives a useful answer and sends it back to the user.

The following diagram illustrates this workflow.

The example described in this post illustrates how the addition of the custom AskHumanTool allows the agent to request clarifying details when needed. This can improve the reliability and accuracy of the responses, leading to a better customer experience in a growing number of RAG applications across different domains.

Clean up

To avoid incurring unnecessary costs, delete the Amazon Kendra index if you’re not using it anymore and shut down the SageMaker Studio instance if you used it to run the demo.

Conclusion

In this post, we showed how to enable a better customer experience for the users of a RAG system by adding a custom tool that enables the system to ask a user for a missing piece of information. This interactive conversational approach represents a promising direction for improving traditional RAG architectures. The ability to resolve vagueness through a dialogue can lead to delivering more satisfactory answers from a knowledge base.

Note that this approach is not limited to RAG use cases; you can use it in other generative AI use cases that depend on an agent at its core, where a custom AskHumanTool can be added.

For more information about using Amazon Kendra with generative AI, refer to Quickly build high-accuracy Generative AI applications on enterprise data using Amazon Kendra, LangChain, and large language models.

About the authors

Antonia Wiebeler is a Data Scientist at the AWS Generative AI Innovation Center, where she enjoys building proofs of concept for customers. Her passion is exploring how generative AI can solve real-world problems and create value for customers. While she is not coding, she enjoys running and competing in triathlons.

Nikita Kozodoi is an Applied Scientist at the AWS Generative AI Innovation Center, where he develops ML solutions to solve customer problems across industries. In his role, he focuses on advancing generative AI to tackle real-world challenges. In his spare time, he loves playing beach volleyball and reading.

Read More

We are witnessing a rapid increase in the adoption of large language models (LLM) that power generative AI applications across industries. LLMs are capable of a variety of tasks, such as generating creative content, answering inquiries via chatbots, generating code, and more.

Organizations looking to use LLMs to power their applications are increasingly wary about data privacy to ensure trust and safety is maintained within their generative AI applications. This includes handling customers’ personally identifiable information (PII) data properly. It also includes preventing abusive and unsafe content from being propagated to LLMs and checking that data generated by LLMs follows the same principles.

In this post, we discuss new features powered by Amazon Comprehend that enable seamless integration to ensure data privacy, content safety, and prompt safety in new and existing generative AI applications.

Amazon Comprehend is a natural language processing (NLP) service that uses machine learning (ML) to uncover information in unstructured data and text within documents. In this post, we discuss why trust and safety with LLMs matter for your workloads. We also delve deeper into how these new moderation capabilities are utilized with the popular generative AI development framework LangChain to introduce a customizable trust and safety mechanism for your use case.

Why trust and safety with LLMs matter

Trust and safety are paramount when working with LLMs due to their profound impact on a wide range of applications, from customer support chatbots to content generation. As these models process vast amounts of data and generate humanlike responses, the potential for misuse or unintended outcomes increases. Ensuring that these AI systems operate within ethical and reliable boundaries is crucial, not just for the reputation of businesses that utilize them, but also for preserving the trust of end-users and customers.

Moreover, as LLMs become more integrated into our daily digital experiences, their influence on our perceptions, beliefs, and decisions grows. Ensuring trust and safety with LLMs goes beyond just technical measures; it speaks to the broader responsibility of AI practitioners and organizations to uphold ethical standards. By prioritizing trust and safety, organizations not only protect their users, but also ensure sustainable and responsible growth of AI in society. It can also help to reduce risk of generating harmful content, and help adhere to regulatory requirements.

In the realm of trust and safety, content moderation is a mechanism that addresses various aspects, including but not limited to:

• Privacy – Users can inadvertently provide text that contains sensitive information, jeopardizing their privacy. Detecting and redacting any PII is essential.
• Toxicity – Recognizing and filtering out harmful content, such as hate speech, threats, or abuse, is of utmost importance.
• User intention – Identifying whether the user input (prompt) is safe or unsafe is critical. Unsafe prompts can explicitly or implicitly express malicious intent, such as requesting personal or private information and generating offensive, discriminatory, or illegal content. Prompts may also implicitly express or request advice on medical, legal, political, controversial, personal, or financial

Content moderation with Amazon Comprehend

In this section, we discuss the benefits of content moderation with Amazon Comprehend.

Addressing privacy

Amazon Comprehend already addresses privacy through its existing PII detection and redaction abilities via the DetectPIIEntities and ContainsPIIEntities APIs. These two APIs are backed by NLP models that can detect a large number of PII entities such as Social Security numbers (SSNs), credit card numbers, names, addresses, phone numbers, and so on. For a full list of entities, refer to PII universal entity types. DetectPII also provides character-level position of the PII entity within a text; for example, the start character position of the NAME entity (John Doe) in the sentence “My name is John Doe” is 12, and the end character position is 19. These offsets can be used to perform masking or redaction of the values, thereby reducing risks of private data propagation into LLMs.

Addressing toxicity and prompt safety

Today, we are announcing two new Amazon Comprehend features in the form of APIs: Toxicity detection via the DetectToxicContent API, and prompt safety classification via the ClassifyDocument API. Note that DetectToxicContent is a new API, whereas ClassifyDocument is an existing API that now supports prompt safety classification.

Toxicity detection

With Amazon Comprehend toxicity detection, you can identify and flag content that may be harmful, offensive, or inappropriate. This capability is particularly valuable for platforms where users generate content, such as social media sites, forums, chatbots, comment sections, and applications that use LLMs to generate content. The primary goal is to maintain a positive and safe environment by preventing the dissemination of toxic content.

At its core, the toxicity detection model analyzes text to determine the likelihood of it containing hateful content, threats, obscenities, or other forms of harmful text. The model is trained on vast datasets containing examples of both toxic and nontoxic content. The toxicity API evaluates a given piece of text to provide toxicity classification and confidence score. Generative AI applications can then use this information to take appropriate actions, such as stopping the text from propagating to LLMs. As of this writing, the labels detected by the toxicity detection API are HATE_SPEECH, GRAPHIC, HARRASMENT_OR_ABUSE, SEXUAL, VIOLENCE_OR_THREAT, INSULT, and PROFANITY. The following code demonstrates the API call with Python Boto3 for Amazon Comprehend toxicity detection:

import boto3
client = boto3.client('comprehend')
response = client.detect_toxic_content(
    	TextSegments=[{"Text": "What is the capital of France?"},
                      {"Text": "Where do I find good baguette in France?"}],
    	LanguageCode='en')
print(response)

Prompt safety classification

Prompt safety classification with Amazon Comprehend helps classify an input text prompt as safe or unsafe. This capability is crucial for applications like chatbots, virtual assistants, or content moderation tools where understanding the safety of a prompt can determine responses, actions, or content propagation to LLMs.

In essence, prompt safety classification analyzes human input for any explicit or implicit malicious intent, such as requesting personal or private information and generation of offensive, discriminatory, or illegal content. It also flags prompts looking for advice on medical, legal, political, controversial, personal, or financial subjects. Prompt classification returns two classes, UNSAFE_PROMPT and SAFE_PROMPT, for an associated text, with an associated confidence score for each. The confidence score ranges between 0–1 and combined will sum up to 1. For instance, in a customer support chatbot, the text “How do I reset my password?” signals an intent to seek guidance on password reset procedures and is labeled as SAFE_PROMPT. Similarly, a statement like “I wish something bad happens to you” can be flagged for having a potentially harmful intent and labeled as UNSAFE_PROMPT. It’s important to note that prompt safety classification is primarily focused on detecting intent from human inputs (prompts), rather than machine-generated text (LLM outputs). The following code demonstrates how to access the prompt safety classification feature with the ClassifyDocument API:

import boto3
client = boto3.client('comprehend')
response = self.client.classify_document(
           		Text=prompt_value,
EndpointArn=endpoint_arn)
print(response)

Note that endpoint_arn in the preceding code is an AWS-provided Amazon Resource Number (ARN) of the pattern arn:aws:comprehend:<region>:aws:document-classifier-endpoint/prompt-safety, where <region> is the AWS Region of your choice where Amazon Comprehend is available.

To demonstrate these capabilities, we built a sample chat application where we ask an LLM to extract PII entities such as address, phone number, and SSN from a given piece of text. The LLM finds and returns the appropriate PII entities, as shown in the image on the left.

With Amazon Comprehend moderation, we can redact the input to the LLM and output from the LLM. In the image on the right, the SSN value is allowed to be passed to the LLM without redaction. However, any SSN value in the LLM’s response is redacted.

The following is an example of how a prompt containing PII information can be prevented from reaching the LLM altogether. This example demonstrates a user asking a question that contains PII information. We use Amazon Comprehend moderation to detect PII entities in the prompt and show an error by interrupting the flow.

The preceding chat examples showcase how Amazon Comprehend moderation applies restrictions on data being sent to an LLM. In the following sections, we explain how this moderation mechanism is implemented using LangChain.

Integration with LangChain

With the endless possibilities of the application of LLMs into various use cases, it has become equally important to simplify the development of generative AI applications. LangChain is a popular open source framework that makes it effortless to develop generative AI applications. Amazon Comprehend moderation extends the LangChain framework to offer PII identification and redaction, toxicity detection, and prompt safety classification capabilities via AmazonComprehendModerationChain.

AmazonComprehendModerationChain is a custom implementation of the LangChain base chain interface. This means that applications can use this chain with their own LLM chains to apply the desired moderation to the input prompt as well as to the output text from the LLM. Chains can be built by merging numerous chains or by mixing chains with other components. You can use AmazonComprehendModerationChain with other LLM chains to develop complex AI applications in a modular and flexible manner.

To explain it further, we provide a few samples in the following sections. The source code for the AmazonComprehendModerationChain implementation can be found within the LangChain open source repository. For full documentation of the API interface, refer to the LangChain API documentation for the Amazon Comprehend moderation chain. Using this moderation chain is as simple as initializing an instance of the class with default configurations:

from langchain_experimental.comprehend_moderation import AmazonComprehendModerationChain

comprehend_moderation = AmazonComprehendModerationChain()

Behind the scenes, the moderation chain performs three consecutive moderation checks, namely PII, toxicity, and prompt safety, as explained in the following diagram. This is the default flow for the moderation.

The following code snippet shows a simple example of using the moderation chain with the Amazon FalconLite LLM (which is a quantized version of the Falcon 40B SFT OASST-TOP1 model) hosted in Hugging Face Hub:

from langchain import HuggingFaceHub
from langchain import PromptTemplate, LLMChain
from langchain_experimental.comprehend_moderation import AmazonComprehendModerationChain

template = """Question: {question}
Answer:"""
repo_id = "amazon/FalconLite"
prompt = PromptTemplate(template=template, input_variables=["question"])
llm = HuggingFaceHub(
repo_id=repo_id,
model_kwargs={"temperature": 0.5, "max_length": 256}
)
comprehend_moderation = AmazonComprehendModerationChain(verbose=True)
chain = (
    prompt
    | comprehend_moderation
    | { "input" : (lambda x: x['output']) | llm }
    | comprehend_moderation
)

try:
    response = chain.invoke({"question": "An SSN is of the format 123-45-6789. Can you give me John Doe's SSN?"})
except Exception as e:
    print(str(e))
else:
    print(response['output'])

In the preceding example, we augment our chain with comprehend_moderation for both text going into the LLM and text generated by the LLM. This will perform default moderation that will check PII, toxicity, and prompt safety classification in that sequence.

Customize your moderation with filter configurations

You can use the AmazonComprehendModerationChain with specific configurations, which gives you the ability to control what moderations you wish to perform in your generative AI–based application. At the core of the configuration, you have three filter configurations available.

1. ModerationPiiConfig – Used to configure PII filter.
2. ModerationToxicityConfig – Used to configure toxic content filter.
3. ModerationIntentConfig – Used to configure intent filter.

You can use each of these filter configurations to customize the behavior of how your moderations behave. Each filter’s configurations have a few common parameters, and some unique parameters, that they can be initialized with. After you define the configurations, you use the BaseModerationConfig class to define the sequence in which the filters must apply to the text. For example, in the following code, we first define the three filter configurations, and subsequently specify the order in which they must apply:

from langchain_experimental.comprehend_moderation
import (BaseModerationConfig,
ModerationPromptSafetyConfig,
ModerationPiiConfig,
ModerationToxicityConfig)

pii_config = ModerationPiiConfig(labels=["SSN"],
   redact=True,
   mask_character="X")
toxicity_config = ModerationToxicityConfig(threshold=0.6)
prompt_safety_config = ModerationPromptSafetyConfig(threshold=0.8)
moderation_config = BaseModerationConfig(filters=[ toxicity_config,
      pii_config,
      prompt_safety_config])
comprehend_moderation = AmazonComprehendModerationChain(moderation_config=moderation_config)

Let’s dive a little deeper to understand what this configuration achieves:

• First, for the toxicity filter, we specified a threshold of 0.6. This means that if the text contains any of the available toxic labels or entities with a score greater than the threshold, the whole chain will be interrupted.
• If there is no toxic content found in the text, a PII check is In this case, we’re interested in checking if the text contains SSN values. Because the redact parameter is set to True, the chain will mask the detected SSN values (if any) where the SSN entitiy’s confidence score is greater than or equal to 0.5, with the mask character specified (X). If redact is set to False, the chain will be interrupted for any SSN detected.
• Finally, the chain performs prompt safety classification, and will stop the content from propagating further down the chain if the content is classified with UNSAFE_PROMPT with a confidence score of greater than or equal to 0.8.

The following diagram illustrates this workflow.

In case of interruptions to the moderation chain (in this example, applicable for the toxicity and prompt safety classification filters), the chain will raise a Python exception, essentially stopping the chain in progress and allowing you to catch the exception (in a try-catch block) and perform any relevant action. The three possible exception types are:

1. ModerationPIIError
2. ModerationToxicityError
3. ModerationPromptSafetyError

You can configure one filter or more than one filter using BaseModerationConfig. You can also have the same type of filter with different configurations within the same chain. For example, if your use case is only concerned with PII, you can specify a configuration that must interrupt the chain if in case an SSN is detected; otherwise, it must perform redaction on age and name PII entities. A configuration for this can be defined as follows:

pii_config1 = ModerationPiiConfig(labels=["SSN"],
    redact=False)
pii_config2 = ModerationPiiConfig(labels=["AGE", "NAME"],
    redact=True,
    mask_character="X")
moderation_config = BaseModerationConfig(filters=[ pii_config1,
      pii_config2])
comprehend_moderation = AmazonComprehendModerationChain(moderation_config=moderation_config)

Using callbacks and unique identifiers

If you’re familiar with the concept of workflows, you may also be familiar with callbacks. Callbacks within workflows are independent pieces of code that run when certain conditions are met within the workflow. A callback can either be blocking or nonblocking to the workflow. LangChain chains are, in essence, workflows for LLMs. AmazonComprehendModerationChain allows you to define your own callback functions. Initially, the implementation is limited to asynchronous (nonblocking) callback functions only.

This effectively means that if you use callbacks with the moderation chain, they will run independently of the chain’s run without blocking it. For the moderation chain, you get options to run pieces of code, with any business logic, after each moderation is run, independent of the chain.

You can also optionally provide an arbitrary unique identifier string when creating an AmazonComprehendModerationChain to enable logging and analytics later. For example, if you’re operating a chatbot powered by an LLM, you may want to track users who are consistently abusive or are deliberately or unknowingly exposing personal information. In such cases, it becomes necessary to track the origin of such prompts and perhaps store them in a database or log them appropriately for further action. You can pass a unique ID that distinctly identifies a user, such as their user name or email, or an application name that is generating the prompt.

The combination of callbacks and unique identifiers provides you with a powerful way to implement a moderation chain that fits your use case in a much more cohesive manner with less code that is easier to maintain. The callback handler is available via the BaseModerationCallbackHandler, with three available callbacks: on_after_pii(), on_after_toxicity(), and on_after_prompt_safety(). Each of these callback functions is called asynchronously after the respective moderation check is performed within the chain. These functions also receive two default parameters:

• moderation_beacon – A dictionary containing details such as the text on which the moderation was performed, the full JSON output of the Amazon Comprehend API, the type of moderation, and if the supplied labels (in the configuration) were found within the text or not
• unique_id – The unique ID that you assigned while initializing an instance of the AmazonComprehendModerationChain.

The following is an example of how an implementation with callback works. In this case, we defined a single callback that we want the chain to run after the PII check is performed:

from langchain_experimental.comprehend_moderation import BaseModerationCallbackHandler

class MyModCallback(BaseModerationCallbackHandler):
    async def on_after_pii(self, output_beacon, unique_id):
        import json
        moderation_type = output_beacon['moderation_type']
        chain_id = output_beacon['moderation_chain_id']
        with open(f'output-{moderation_type}-{chain_id}.json', 'w') as file:
            data = { 'beacon_data': output_beacon, 'unique_id': unique_id }
            json.dump(data, file)

    '''
    # implement this callback for toxicity
    async def on_after_toxicity(self, output_beacon, unique_id):
        pass

    # implement this callback for prompt safety
    async def on_after_prompt_safety(self, output_beacon, unique_id):
        pass
    '''

my_callback = MyModCallback()

We then use the my_callback object while initializing the moderation chain and also pass a unique_id. You may use callbacks and unique identifiers with or without a configuration. When you subclass BaseModerationCallbackHandler, you must implement one or all of the callback methods depending on the filters you intend to use. For brevity, the following example shows a way to use callbacks and unique_id without any configuration:

comprehend_moderation = AmazonComprehendModerationChain(
moderation_callback = my_callback,
unique_id = 'john.doe@email.com')

The following diagram explains how this moderation chain with callbacks and unique identifiers works. Specifically, we implemented the PII callback that should write a JSON file with the data available in the moderation_beacon and the unique_id passed (the user’s email in this case).

In the following Python notebook, we have compiled a few different ways you can configure and use the moderation chain with various LLMs, such as LLMs hosted with Amazon SageMaker JumpStart and hosted in Hugging Face Hub. We have also included the sample chat application that we discussed earlier with the following Python notebook.

Conclusion

The transformative potential of large language models and generative AI is undeniable. However, their responsible and ethical use hinges on addressing concerns of trust and safety. By recognizing the challenges and actively implementing measures to mitigate risks, developers, organizations, and society at large can harness the benefits of these technologies while preserving the trust and safety that underpin their successful integration. Use Amazon Comprehend ContentModerationChain to add trust and safety features to any LLM workflow, including Retrieval Augmented Generation (RAG) workflows implemented in LangChain.

For information on building RAG based solutions using LangChain and Amazon Kendra’s highly accurate, machine learning (ML)-powered intelligent search, see – Quickly build high-accuracy Generative AI applications on enterprise data using Amazon Kendra, LangChain, and large language models. As a next step, refer to the code samples we created for using Amazon Comprehend moderation with LangChain. For full documentation of the Amazon Comprehend moderation chain API, refer to the LangChain API documentation.

About the authors

Wrick Talukdar is a Senior Architect with the Amazon Comprehend Service team. He works with AWS customers to help them adopt machine learning on a large scale. Outside of work, he enjoys reading and photography.

Anjan Biswas is a Senior AI Services Solutions Architect with a focus on AI/ML and Data Analytics. Anjan is part of the world-wide AI services team and works with customers to help them understand and develop solutions to business problems with AI and ML. Anjan has over 14 years of experience working with global supply chain, manufacturing, and retail organizations, and is actively helping customers get started and scale on AWS AI services.

Nikhil Jha is a Senior Technical Account Manager at Amazon Web Services. His focus areas include AI/ML, and analytics. In his spare time, he enjoys playing badminton with his daughter and exploring the outdoors.

Chin Rane is an AI/ML Specialist Solutions Architect at Amazon Web Services. She is passionate about applied mathematics and machine learning. She focuses on designing intelligent document processing solutions for AWS customers. Outside of work, she enjoys salsa and bachata dancing.

Read More

In the recent past, using machine learning (ML) to make predictions, especially for data in the form of text and images, required extensive ML knowledge for creating and tuning of deep learning models. Today, ML has become more accessible to any user who wants to use ML models to generate business value. With Amazon SageMaker Canvas, you can create predictions for a number of different data types beyond just tabular or time series data without writing a single line of code. These capabilities include pre-trained models for image, text, and document data types.

In this post, we discuss how you can use pre-trained models to retrieve predictions for supported data types beyond tabular data.

Text data

SageMaker Canvas provides a visual, no-code environment for building, training, and deploying ML models. For natural language processing (NLP) tasks, SageMaker Canvas integrates seamlessly with Amazon Comprehend to allow you to perform key NLP capabilities like language detection, entity recognition, sentiment analysis, topic modeling, and more. The integration eliminates the need for any coding or data engineering to use the robust NLP models of Amazon Comprehend. You simply provide your text data and select from four commonly used capabilities: sentiment analysis, language detection, entities extraction, and personal information detection. For each scenario, you can use the UI to test and use batch prediction to select data stored in Amazon Simple Storage Service (Amazon S3).

Sentiment analysis

With sentiment analysis, SageMaker Canvas allows you to analyze the sentiment of your input text. It can determine if the overall sentiment is positive, negative, mixed, or neutral, as shown in the following screenshot. This is useful in situations like analyzing product reviews. For example, the text “I love this product, it’s amazing!” would be classified by SageMaker Canvas as having a positive sentiment, whereas “This product is horrible, I regret buying it” would be labeled as negative sentiment.

Entities extraction

SageMaker Canvas can analyze text and automatically detect entities mentioned within it. When a document is sent to SageMaker Canvas for analysis, it will identify people, organizations, locations, dates, quantities, and other entities in the text. This entity extraction capability enables you to quickly gain insights into the key people, places, and details discussed in documents. For a list of supported entities, refer to Entities.

Language detection

SageMaker Canvas can also determine the dominant language of text using Amazon Comprehend. It analyzes text to identify the main language and provides confidence scores for the detected dominant language, but doesn’t indicate percentage breakdowns for multilingual documents. For best results with long documents in multiple languages, split the text into smaller pieces and aggregate the results to estimate language percentages. It works best with at least 20 characters of text.

Personal information detection

You can also protect sensitive data using personal information detection with SageMaker Canvas. It can analyze text documents to automatically detect personally identifiable information (PII) entities, allowing you to locate sensitive data like names, addresses, dates of birth, phone numbers, email addresses, and more. It analyzes documents up to 100 KB and provides a confidence score for each detected entity so you can review and selectively redact the most sensitive information. For a list of entities detected, refer to Detecting PII entities.

Image data

SageMaker Canvas provides a visual, no-code interface that makes it straightforward for you to use computer vision capabilities by integrating with Amazon Rekognition for image analysis. For example, you can upload a dataset of images, use Amazon Rekognition to detect objects and scenes, and perform text detection to address a wide range of use cases. The visual interface and Amazon Rekognition integration make it possible for non-developers to harness advanced computer vision techniques.

Object detection in images

SageMaker Canvas uses Amazon Rekognition to detect labels (objects) in an image. You can upload the image from the SageMaker Canvas UI or use the Batch Prediction tab to select images stored in an S3 bucket. As shown in the following example, it can extract objects in the image such as clock tower, bus, buildings, and more. You can use the interface to search through the prediction results and sort them.

Text detection in images

Extracting text from images is a very common use case. Now, you can perform this task with ease on SageMaker Canvas with no code. The text is extracted as line items, as shown in the following screenshot. Short phrases within the image are classified together and identified as a phrase.

You can perform batch predictions by uploading a set of images, extract all the images in a single batch job, and download the results as a CSV file. This solution is useful when you want to extract and detect text in images.

Document data

SageMaker Canvas offers a variety of ready-to-use solutions that solve your day-to-day document understanding needs. These solutions are powered by Amazon Textract. To view all the available options for documents, choose to Ready-to-use models in the navigation pane and filter by Documents, as shown in the following screenshot.

Document analysis

Document analysis analyzes documents and forms for relationships among detected text. The operations return four categories of document extraction: raw text, forms, tables, and signatures. The solution’s capability of understanding the document structure gives you extra flexibility in the type of data you want to extract from the documents. The following screenshot is an example of what table detection looks like.

This solution is able to understand layouts of complex documents, which is helpful when you need to extract specific information in your documents.

Identity document analysis

This solution is designed to analyze documents like personal identification cards, driver’s licenses, or other similar forms of identification. Information such as middle name, county, and place of birth, together with its individual confidence score on the accuracy, will be returned for each identity document, as shown in the following screenshot.

There is an option to do batch prediction, whereby you can bulk upload sets of identification documents and process them as a batch job. This provides a quick and seamless way to transform identification document details into key-value pairs that can be used for downstream processes such as data analysis.

Expense analysis

Expense analysis is designed to analyze expense documents like invoices and receipts. The following screenshot is an example of what the extracted information looks like.

The results are returned as summary fields and line item fields. Summary fields are key-value pairs extracted from the document, and contain keys such as Grand Total, Due Date, and Tax. Line item fields refer to data that is structured as a table in the document. This is useful for extracting information from the document while retaining its layout.

Document queries

Document queries are designed for you to ask questions about your documents. This is a great solution to use when you have multi-page documents and you want to extract very specific answers from your documents. The following is an example of the types of questions you can ask and what the extracted answers look like.

The solution provides a straightforward interface for you to interact with your documents. This is helpful when you want to get specific details within large documents.

Conclusion

SageMaker Canvas provides a no-code environment to use ML with ease across various data types like text, images, and documents. The visual interface and integration with AWS services like Amazon Comprehend, Amazon Rekognition, and Amazon Textract eliminates the need for coding and data engineering. You can analyze text for sentiment, entities, languages, and PII. For images, object and text detection enables computer vision use cases. Finally, document analysis can extract text while preserving its layout for downstream processes. The ready-to-use solutions in SageMaker Canvas make it possible for you to harness advanced ML techniques to generate insights from both structured and unstructured data. If you’re interested using no-code tools with ready-to-use ML models, try out SageMaker Canvas today. For more information, refer to Getting started with using Amazon SageMaker Canvas.

About the authors

Julia Ang is a Solutions Architect based in Singapore. She has worked with customers in a range of fields, from health and public sector to digital native businesses, to adopt solutions according to their business needs. She has also been supporting customers in Southeast Asia and beyond to use AI & ML in their businesses. Outside of work, she enjoys learning about the world through traveling and engaging in creative pursuits.

Loke Jun Kai is a Specialist Solutions Architect for AI/ML based in Singapore. He works with customer across ASEAN to architect machine learning solutions at scale in AWS. Jun Kai is an advocate for Low-Code No-Code machine learning tools. In his spare time, he enjoys being with the nature.

Read More

Creating high-performance machine learning (ML) solutions relies on exploring and optimizing training parameters, also known as hyperparameters. Hyperparameters are the knobs and levers that we use to adjust the training process, such as learning rate, batch size, regularization strength, and others, depending on the specific model and task at hand. Exploring hyperparameters involves systematically varying the values of each parameter and observing the impact on model performance. Although this process requires additional efforts, the benefits are significant. Hyperparameter optimization (HPO) can lead to faster training times, improved model accuracy, and better generalization to new data.

We continue our journey from the post Optimize hyperparameters with Amazon SageMaker Automatic Model Tuning. We previously explored a single job optimization, visualized the outcomes for SageMaker built-in algorithm, and learned about the impact of particular hyperparameter values. On top of using HPO as a one-time optimization at the end of the model creation cycle, we can also use it across multiple steps in a conversational manner. Each tuning job helps us get closer to a good performance, but additionally, we also learn how sensitive the model is to certain hyperparameters and can use this understanding to inform the next tuning job. We can revise the hyperparameters and their value ranges based on what we learned and therefore turn this optimization effort into a conversation. And in the same way that we as ML practitioners accumulate knowledge over these runs, Amazon SageMaker Automatic Model Tuning (AMT) with warm starts can maintain this knowledge acquired in previous tuning jobs for the next tuning job as well.

In this post, we run multiple HPO jobs with a custom training algorithm and different HPO strategies such as Bayesian optimization and random search. We also put warm starts into action and visually compare our trials to refine hyperparameter space exploration.

Advanced concepts of SageMaker AMT

In the next sections, we take a closer look at each of the following topics and show how SageMaker AMT can help you implement them in your ML projects:

• Use custom training code and the popular ML framework Scikit-learn in SageMaker Training
• Define custom evaluation metrics based on the logs for evaluation and optimization
• Perform HPO using an appropriate strategy
• Use warm starts to turn a single hyperparameter search into a dialog with our model
• Use advanced visualization techniques using our solution library to compare two HPO strategies and tuning jobs results

Whether you’re using the built-in algorithms used in our first post or your own training code, SageMaker AMT offers a seamless user experience for optimizing ML models. It provides key functionality that allows you to focus on the ML problem at hand while automatically keeping track of the trials and results. At the same time, it automatically manages the underlying infrastructure for you.

In this post, we move away from a SageMaker built-in algorithm and use custom code. We use a Random Forest from SkLearn. But we stick to the same ML task and dataset as in our first post, which is detecting handwritten digits. We cover the content of the Jupyter notebook 2_advanced_tuning_with_custom_training_and_visualizing.ipynb and invite you to invoke the code side by side to read further.

Let’s dive deeper and discover how we can use custom training code, deploy it, and run it, while exploring the hyperparameter search space to optimize our results.

How to build an ML model and perform hyperparameter optimization

What does a typical process for building an ML solution look like? Although there are many possible use cases and a large variety of ML tasks out there, we suggest the following mental model for a stepwise approach:

1. Understand your ML scenario at hand and select an algorithm based on the requirements. For example, you might want to solve an image recognition task using a supervised learning algorithm. In this post, we continue to use the handwritten image recognition scenario and the same dataset as in our first post.
2. Decide which implementation of the algorithm in SageMaker Training you want to use. There are various options, inside SageMaker or external ones. Additionally, you need to define which underlying metric fits best for your task and you want to optimize for (such as accuracy, F1 score, or ROC). SageMaker supports four options depending on your needs and resources:
   • Use a pre-trained model via Amazon SageMaker JumpStart, which you can use out of the box or just fine-tune it.
   • Use one of the built-in algorithms for training and tuning, like XGBoost, as we did in our previous post.
   • Train and tune a custom model based on one of the major frameworks like Scikit-learn, TensorFlow, or PyTorch. AWS provides a selection of pre-made Docker images for this purpose. For this post, we use this option, which allows you to experiment quickly by running your own code on top of a pre-made container image.
   • Bring your own custom Docker image in case you want to use a framework or software that is not otherwise supported. This option requires the most effort, but also provides the highest degree of flexibility and control.
3. Train the model with your data. Depending on the algorithm implementation from the previous step, this can be as simple as referencing your training data and running the training job or by additionally providing custom code for training. In our case, we use some custom training code in Python based on Scikit-learn.
4. Apply hyperparameter optimization (as a “conversation” with your ML model). After the training, you typically want to optimize the performance of your model by finding the most promising combination of values for your algorithm’s hyperparameters.

Depending on your ML algorithm and model size, the last step of hyperparameter optimization may turn out to be a bigger challenge than expected. The following questions are typical for ML practitioners at this stage and might sound familiar to you:

• What kind of hyperparameters are impactful for my ML problem?
• How can I effectively search a huge hyperparameter space to find those best-performing values?
• How does the combination of certain hyperparameter values influence my performance metric?
• Costs matter; how can I use my resources in an efficient manner?
• What kind of tuning experiments are worthwhile, and how can I compare them?

It’s not easy to answer these questions, but there is good news. SageMaker AMT takes the heavy lifting from you, and lets you concentrate on choosing the right HPO strategy and value ranges you want to explore. Additionally, our visualization solution facilitates the iterative analysis and experimentation process to efficiently find well-performing hyperparameter values.

In the next sections, we build a digit recognition model from scratch using Scikit-learn and show all these concepts in action.

Solution overview

SageMaker offers some very handy features to train, evaluate, and tune our model. It covers all functionality of an end-to-end ML lifecycle, so we don’t even need to leave our Jupyter notebook.

In our first post, we used the SageMaker built-in algorithm XGBoost. For demonstration purposes, this time we switch to a Random Forest classifier because we can then show how to provide your own training code. We opted for providing our own Python script and using Scikit-learn as our framework. Now, how do we express that we want to use a specific ML framework? As we will see, SageMaker uses another AWS service in the background to retrieve a pre-built Docker container image for training—Amazon Elastic Container Registry (Amazon ECR).

We cover the following steps in detail, including code snippets and diagrams to connect the dots. As mentioned before, if you have the chance, open the notebook and run the code cells step by step to create the artifacts in your AWS environment. There is no better way of active learning.

1. First, load and prepare the data. We use Amazon Simple Storage Service (Amazon S3) to upload a file containing our handwritten digits data.
2. Next, prepare the training script and framework dependencies. We provide the custom training code in Python, reference some dependent libraries, and make a test run.
3. To define the custom objective metrics, SageMaker lets us define a regular expression to extract the metrics we need from the container log files.
4. Train the model using the scikit-learn framework. By referencing a pre-built container image, we create a corresponding Estimator object and pass our custom training script.
5. AMT enables us to try out various HPO strategies. We concentrate on two of them for this post: random search and Bayesian search.
6. Choose between SageMaker HPO strategies.
7. Visualize, analyze, and compare tuning results. Our visualization package allows us to discover which strategy performs better and which hyperparameter values deliver the best performance based on our metrics.
8. Continue the exploration of the hyperparameter space and warm start HPO jobs.

AMT takes care of scaling and managing the underlying compute infrastructure to run the various tuning jobs on Amazon Elastic Compute Cloud (Amazon EC2) instances. This way, you don’t need to burden yourself to provision instances, handle any operating system and hardware issues, or aggregate log files on your own. The ML framework image is retrieved from Amazon ECR and the model artifacts including tuning results are stored in Amazon S3. All logs and metrics are collected in Amazon CloudWatch for convenient access and further analysis if needed.

Prerequisites

Because this is a continuation of a series, it is recommended, but not necessarily required, to read our first post about SageMaker AMT and HPO. Apart from that, basic familiarity with ML concepts and Python programming is helpful. We also recommend following along with each step in the accompanying notebook from our GitHub repository while reading this post. The notebook can be run independently from the first one, but needs some code from subfolders. Make sure to clone the full repository in your environment as described in the README file.

Experimenting with the code and using the interactive visualization options greatly enhances your learning experience. So, please check it out.

Load and prepare the data

As a first step, we make sure the downloaded digits data we need for training is accessible to SageMaker. Amazon S3 allows us to do this in a safe and scalable way. Refer to the notebook for the complete source code and feel free to adapt it with your own data.

sm_sess = sagemaker.session.Session(boto_session=boto_sess, sagemaker_client=sm)
BUCKET = sm_sess.default_bucket()
PREFIX = 'amt-visualize-demo'
s3_data_url = f's3://{BUCKET}/{PREFIX}/data'
digits         = datasets.load_digits()
digits_df      = pd.DataFrame(digits.data)
digits_df['y'] = digits.target
digits_df.to_csv('data/digits.csv', index=False)
!aws s3 sync data/ {s3_data_url} —exclude '*' —include 'digits.csv'

The digits.csv file contains feature data and labels. Each digit is represented by pixel values in an 8×8 image, as depicted by the following image for the digit 4.

Prepare the training script and framework dependencies

Now that the data is stored in our S3 bucket, we can define our custom training script based on Scikit-learn in Python. SageMaker gives us the option to simply reference the Python file later for training. Any dependencies like the Scikit-learn or pandas libraries can be provided in two ways:

• They can be specified explicitly in a requirements.txt file
• They are pre-installed in the underlying ML container image, which is either provided by SageMaker or custom-built

Both options are generally considered standard ways for dependency management, so you might already be familiar with it. SageMaker supports a variety of ML frameworks in a ready-to-use managed environment. This includes many of the most popular data science and ML frameworks like PyTorch, TensorFlow, or Scikit-learn, as in our case. We don’t use an additional requirements.txt file, but feel free to add some libraries to try it out.

The code of our implementation contains a method called fit(), which creates a new classifier for the digit recognition task and trains it. In contrast to our first post where we used the SageMaker built-in XGBoost algorithm, we now use a RandomForestClassifier provided by the ML library sklearn. The call of the fit() method on the classifier object starts the training process using a subset (80%) of our CSV data:

def fit(train_dir, n_estimators, max_depth, min_samples_leaf, max_features, min_weight_fraction_leaf):

    digits = pd.read_csv(Path(train_dir)/'digits.csv')

    Xtrain, Xtest, ytrain, ytest = train_test_split(digits.iloc[:, :-1], digits.iloc[:, -1], test_size=.2)

    m = RandomForestClassifier(n_estimators=n_estimators,
                               max_depth=max_depth,
                               min_samples_leaf=min_samples_leaf,
                               max_features=max_features,
                               min_weight_fraction_leaf=min_weight_fraction_leaf)
    m.fit(Xtrain, ytrain)
    predicted = m.predict(Xtest)
    pre, rec, f1, _ = precision_recall_fscore_support(ytest, predicted, pos_label=1, average='weighted')

    print(f'pre: {pre:5.3f} rec: {rec:5.3f} f1: {f1:5.3}')

    return m

See the full script in our Jupyter notebook on GitHub.

Before you spin up container resources for the full training process, did you try to run the script directly? This is a good practice to quickly ensure the code has no syntax errors, check for matching dimensions of your data structures, and some other errors early on.

There are two ways to run your code locally. First, you can run it right away in the notebook, which also allows you to use the Python Debugger pdb:

# Running the code from within the notebook. It would then be possible to use the Python Debugger, pdb.
from train import fit
fit('data', 100, 10, 1, 'auto', 0.01)

Alternatively, run the train script from the command line in the same way you may want to use it in a container. This also supports setting various parameters and overwriting the default values as needed, for example:

!cd src && python train.py --train ../data/ --model-dir /tmp/ --n-estimators 100

As output, you can see the first results for the model’s performance based on the objective metrics precision, recall, and F1-score. For example, pre: 0.970 rec: 0.969 f1: 0.969.

Not bad for such a quick training. But where did these numbers come from and what do we do with them?

Define custom objective metrics

Remember, our goal is to fully train and tune our model based on the objective metrics we consider relevant for our task. Because we use a custom training script, we need to define those metrics for SageMaker explicitly.

Our script emits the metrics precision, recall, and F1-score during training simply by using the print function:

print(f'pre: {pre:5.3f} rec: {rec:5.3f} f1: {f1:5.3}')

The standard output is captured by SageMaker and sent to CloudWatch as a log stream. To retrieve the metric values and work with them later in SageMaker AMT, we need to provide some information on how to parse that output. We can achieve this by defining regular expression statements (for more information, refer to Monitor and Analyze Training Jobs Using Amazon CloudWatch Metrics):

metric_definitions = [
    {'Name': 'valid-precision',  'Regex': r'pre:s+(-?[0-9.]+)'},
    {'Name': 'valid-recall',     'Regex': r'rec:s+(-?[0-9.]+)'},
    {'Name': 'valid-f1',         'Regex': r'f1:s+(-?[0-9.]+)'}]

Let’s walk through the first metric definition in the preceding code together. SageMaker will look for output in the log that starts with pre: and is followed by one or more whitespace and then a number that we want to extract, which is why we use the round parenthesis. Every time SageMaker finds a value like that, it turns it into a CloudWatch metric with the name valid-precision.

Train the model using the Scikit-learn framework

After we create our training script train.py and instruct SageMaker on how to monitor the metrics within CloudWatch, we define a SageMaker Estimator object. It initiates the training job and uses the instance type we specify. But how can this instance type be different from the one you run an Amazon SageMaker Studio notebook on, and why? SageMaker Studio runs your training (and inference) jobs on separate compute instances than your notebook. This allows you to continue working in your notebook while the jobs run in the background.

The parameter framework_version refers to the Scikit-learn version we use for our training job. Alternatively, we can pass image_uri to the estimator. You can check whether your favorite framework or ML library is available as a pre-built SageMaker Docker image and use it as is or with extensions.

Moreover, we can run SageMaker training jobs on EC2 Spot Instances by setting use_spot_instances to True. They are spare capacity instances that can save up to 90% of costs.  These instances provide flexibility on when the training jobs are run.

estimator = SKLearn(
    'train.py',
    source_dir='src',
    role=get_execution_role(),
    instance_type= 'ml.m5.large',
    instance_count=1,
    framework_version='0.23-1',
    metric_definitions=metric_definitions,

    # Uncomment the following three lines to use Managed Spot Training
    # use_spot_instances= True,
    # max_run=  60 * 60 * 24,
    # max_wait= 60 * 60 * 24,

    hyperparameters = {'n-estimators': 100,
                       'max-depth': 10,
                       'min-samples-leaf': 1,
                       'max-features': 'auto',
                       'min-weight-fraction-leaf': 0.1}
)

After the Estimator object is set up, we start the training by calling the fit() function, supplying the path to the training dataset on Amazon S3. We can use this same method to provide validation and test data. We set the wait parameter to True so we can use the trained model in the subsequent code cells.

estimator.fit({'train': s3_data_url}, wait=True)

Define hyperparameters and run tuning jobs

So far, we have trained the model with one set of hyperparameter values. But were those values good? Or could we look for better ones? Let’s use the HyperparameterTuner class to run a systematic search over the hyperparameter space. How do we search this space with the tuner? The necessary parameters are the objective metric name and objective type that will guide the optimization. The optimization strategy is another key argument for the tuner because it further defines the search space. The following are four different strategies to choose from:

• Grid search
• Random search
• Bayesian optimization (default)
• Hyperband

We further describe these strategies and equip you with some guidance to choose one later in this post.

Before we define and run our tuner object, let’s recap our understanding from an architecture perspective. We covered the architectural overview of SageMaker AMT in our last post and reproduce an excerpt of it here for convenience.

We can choose what hyperparameters we want to tune or leave static. For dynamic hyperparameters, we provide hyperparameter_ranges that can be used to optimize for tunable hyperparameters. Because we use a Random Forest classifier, we have utilized the hyperparameters from the Scikit-learn Random Forest documentation.

We also limit resources with the maximum number of training jobs and parallel training jobs the tuner can use. We will see how these limits help us compare the results of various strategies with each other.

tuner_parameters = {
    'estimator': estimator,
    'base_tuning_job_name': 'random',
    'metric_definitions': metric_definitions,
    'objective_metric_name': 'valid-f1',
    'objective_type': 'Maximize',
    'hyperparameter_ranges': hpt_ranges,
    'strategy': 'Random',
    'max_jobs': n, # 50
    'max_parallel_jobs': k # 2
    }

Similar to the Estimator’s fit function, we start a tuning job calling the tuner’s fit:

random_tuner = HyperparameterTuner(**tuner_parameters)
random_tuner.fit({'train': s3_data_url}, wait=False)

This is all we have to do to let SageMaker run the training jobs (n=50) in the background, each using a different set of hyperparameters. We explore the results later in this post. But before that, let’s start another tuning job, this time applying the Bayesian optimization strategy. We will compare both strategies visually after their completion.

tuner_parameters['strategy']             = 'Bayesian'
tuner_parameters['base_tuning_job_name'] = 'bayesian'
bayesian_tuner = HyperparameterTuner(**tuner_parameters)
bayesian_tuner.fit({'train': s3_data_url}, wait=False)

Note that both tuner jobs can run in parallel because SageMaker orchestrates the required compute instances independently of each other. That’s quite helpful for practitioners who experiment with different approaches at the same time, like we do here.

Choose between SageMaker HPO strategies

When it comes to tuning strategies, you have a few options with SageMaker AMT: grid search, random search, Bayesian optimization, and Hyperband. These strategies determine how the automatic tuning algorithms explore the specified ranges of hyperparameters.

Random search is pretty straightforward. It randomly selects combinations of values from the specified ranges and can be run in a sequential or parallel manner. It’s like throwing darts blindfolded, hoping to hit the target. We have started with this strategy, but will the results improve with another one?

Bayesian optimization takes a different approach than random search. It considers the history of previous selections and chooses values that are likely to yield the best results. If you want to learn from previous explorations, you can achieve this only with running a new tuning job after the previous ones. Makes sense, right? In this way, Bayesian optimization is dependent on the previous runs. But do you see what HPO strategy allows for higher parallelization?

Hyperband is an interesting one! It uses a multi-fidelity strategy, which means it dynamically allocates resources to the most promising training jobs and stops those that are underperforming. Therefore, Hyperband is computationally efficient with resources, learning from previous training jobs. After stopping the underperforming configurations, a new configuration starts, and its values are chosen randomly.

Depending on your needs and the nature of your model, you can choose between random search, Bayesian optimization, or Hyperband as your tuning strategy. Each has its own approach and advantages, so it’s important to consider which one works best for your ML exploration. The good news for ML practitioners is that you can select the best HPO strategy by visually comparing the impact of each trial on the objective metric. In the next section, we see how to visually identify the impact of different strategies.

Visualize, analyze, and compare tuning results

When our tuning jobs are complete, it gets exciting. What results do they deliver? What kind of boost can you expect on our metric compared to your base model? What are the best-performing hyperparameters for our use case?

A quick and straightforward way to view the HPO results is by visiting the SageMaker console. Under Hyperparameter tuning jobs, we can see (per tuning job) the combination of hyperparameter values that have been tested and delivered the best performance as measured by our objective metric (valid-f1).

Is that all you need? As an ML practitioner, you may be not only interested in those values, but certainly want to learn more about the inner workings of your model to explore its full potential and strengthen your intuition with empirical feedback.

A good visualization tool can greatly help you understand the improvement by HPO over time and get empirical feedback on design decisions of your ML model. It shows the impact of each individual hyperparameter on your objective metric and provides guidance to further optimize your tuning results.

We use the amtviz custom visualization package to visualize and analyze tuning jobs. It’s straightforward to use and provides helpful features. We demonstrate its benefit by interpreting some individual charts, and finally comparing random search side by side with Bayesian optimization.

First, let’s create a visualization for random search. We can do this by calling visualize_tuning_job() from amtviz and passing our first tuner object as an argument:

from amtviz import visualize_tuning_job
visualize_tuning_job(random_tuner, advanced=True, trials_only=True)

You will see a couple of charts, but let’s take it step by step. The first scatter plot from the output looks like the following and already gives us some visual clues we wouldn’t recognize in any table.

Each dot represents the performance of an individual training job (our objective valid-f1 on the y-axis) based on its start time (x-axis), produced by a specific set of hyperparameters. Therefore, we look at the performance of our model as it progresses over the duration of the tuning job.

The dotted line highlights the best result found so far and indicates improvement over time. The best two training jobs achieved an F1 score of around 0.91.

Besides the dotted line showing the cumulative progress, do you see a trend in the chart?

Probably not. And this is expected, because we’re viewing the results of the random HPO strategy. Each training job was run using a different but randomly selected set of hyperparameters. If we continued our tuning job (or ran another one with the same setting), we would probably see some better results over time, but we can’t be sure. Randomness is a tricky thing.

The next charts help you gauge the influence of hyperparameters on the overall performance. All hyperparameters are visualized, but for the sake of brevity, we focus on two of them: n-estimators and max-depth.

Our top two training jobs were using n-estimators of around 20 and 80, and max-depth of around 10 and 18, respectively. The exact hyperparameter values are displayed via tooltip for each dot (training job). They are even dynamically highlighted across all charts and give you a multi-dimensional view! Did you see that? Each hyperparameter is plotted against the objective metric, as a separate chart.

Now, what kind of insights do we get about n-estimators?

Based on the left chart, it seems that very low value ranges (below 10) more often deliver poor results compared to higher values. Therefore, higher values may help your model to perform better—interesting.

In contrast, the correlation of the max-depth hyperparameter to our objective metric is rather low. We can’t clearly tell which value ranges are performing better from a general perspective.

In summary, random search can help you find a well-performing set of hyperparameters even in a relatively short amount of time. Also, it isn’t biased towards a good solution but gives a balanced view of the search space. Your resource utilization, however, might not be very efficient. It continues to run training jobs with hyperparameters in value ranges that are known to deliver poor results.

Let’s examine the results of our second tuning job using Bayesian optimization. We can use amtviz to visualize the results in the same way as we did so far for the random search tuner. Or, even better, we can use the capability of the function to compare both tuning jobs in a single set of charts. Quite handy!

visualize_tuning_job([random_tuner, bayesian_tuner], advanced=True, trials_only=True)

There are more dots now because we visualize the results of all training jobs for both, the random search (orange dots) and the Bayesian optimization (blue dots). On the right side, you can see a density chart visualizing the distribution of all F1-scores. A majority of the training jobs achieved results in the upper part of the F1 scale (over 0.6)—that’s good!

What is the key takeaway here? The scatter plot clearly shows the benefit of Bayesian optimization. It delivers better results over time because it can learn from previous runs. That’s why we achieved significantly better results using Bayesian compared to random (0.967 vs. 0.919) with the same number of training jobs.

There is even more you can do with amtviz. Let’s drill in.

If you give SageMaker AMT the instruction to run a larger number of jobs for tuning, seeing many trials at once can get messy. That’s one of the reasons why we made these charts interactive. You can click and drag on every hyperparameter scatter plot to zoom in to certain value ranges and refine your visual interpretation of the results. All other charts are automatically updated. That’s pretty helpful, isn’t it? See the next charts as an example and try it for yourself in your notebook!

As a tuning maximalist, you may also decide that running another hyperparameter tuning job could further improve your model performance. But this time, a more specific range of hyperparameter values can be explored because you already know (roughly) where to expect better results. For example, you may choose to focus on values between 100–200 for n-estimators, as shown in the chart. This lets AMT focus on the most promising training jobs and increases your tuning efficiency.

To sum it up, amtviz provides you with a rich set of visualization capabilities that allow you to better understand the impact of your model’s hyperparameters on performance and enable smarter decisions in your tuning activities.

Continue the exploration of the hyperparameter space and warm start HPO jobs

We have seen that AMT helps us explore the hyperparameter search space efficiently. But what if we need multiple rounds of tuning to iteratively improve our results? As mentioned in the beginning, we want to establish an optimization feedback cycle—our “conversation” with the model. Do we need to start from scratch every time?

Let’s look into the concept of running a warm start hyperparameter tuning job. It doesn’t initiate new tuning jobs from scratch, it reuses what has been learned in the previous HPO runs. This helps us be more efficient with our tuning time and compute resources. We can further iterate on top of our previous results. To use warm starts, we create a WarmStartConfig and specify warm_start_type as IDENTICAL_DATA_AND_ALGORITHM. This means that we change the hyperparameter values but we don’t change the data or algorithm. We tell AMT to transfer the previous knowledge to our new tuning job.

By referring to our previous Bayesian optimization and random search tuning jobs as parents, we can use them both for the warm start:

warm_start_config = WarmStartConfig(warm_start_type=WarmStartTypes.IDENTICAL_DATA_AND_ALGORITHM,
                                    parents=[bayesian_tuner_name, random_tuner_name])
tuner_parameters['warm_start_config'] =  warm_start_config

To see the benefit of using warm starts, refer to the following charts. These are generated by amtviz in a similar way as we did earlier, but this time we have added another tuning job based on a warm start.

In the left chart, we can observe that new tuning jobs mostly lie in the upper-right corner of the performance metric graph (see dots marked in orange). The warm start has indeed reused the previous results, which is why those data points are in the top results for F1 score. This improvement is also reflected in the density chart on the right.

In other words, AMT automatically selects promising sets of hyperparameter values based on its knowledge from previous trials. This is shown in the next chart. For example, the algorithm would test a low value for n-estimators less often because these are known to produce poor F1 scores. We don’t waste any resources on that, thanks to warm starts.

Clean up

To avoid incurring unwanted costs when you’re done experimenting with HPO, you must remove all files in your S3 bucket with the prefix amt-visualize-demo and also shut down SageMaker Studio resources.

Run the following code in your notebook to remove all S3 files from this post:

!aws s3 rm s3://{BUCKET}/amt-visualize-demo --recursive

If you wish to keep the datasets or the model artifacts, you may modify the prefix in the code to amt-visualize-demo/data to only delete the data or amt-visualize-demo/output to only delete the model artifacts.

Conclusion

We have learned how the art of building ML solutions involves exploring and optimizing hyperparameters. Adjusting those knobs and levers is a demanding yet rewarding process that leads to faster training times, improved model accuracy, and overall better ML solutions. The SageMaker AMT functionality helps us run multiple tuning jobs and warm start them, and provides data points for further review, visual comparison, and analysis.

In this post, we looked into HPO strategies that we use with SageMaker AMT. We started with random search, a straightforward but performant strategy where hyperparameters are randomly sampled from a search space. Next, we compared the results to Bayesian optimization, which uses probabilistic models to guide the search for optimal hyperparameters. After we identified a suitable HPO strategy and good hyperparameter value ranges through initial trials, we showed how to use warm starts to streamline future HPO jobs.

You can explore the hyperparameter search space by comparing quantitative results. We have suggested the side-by-side visual comparison and provided the necessary package for interactive exploration. Let us know in the comments how helpful it was for you on your hyperparameter tuning journey!

About the authors

Ümit Yoldas is a Senior Solutions Architect with Amazon Web Services. He works with enterprise customers across industries in Germany. He’s driven to translate AI concepts into real-world solutions. Outside of work, he enjoys time with family, savoring good food, and pursuing fitness.

Elina Lesyk is a Solutions Architect located in Munich. She is focusing on enterprise customers from the financial services industry. In her free time, you can find Elina building applications with generative AI at some IT meetups, driving a new idea on fixing climate change fast, or running in the forest to prepare for a half-marathon with a typical deviation from the planned schedule.

Mariano Kamp is a Principal Solutions Architect with Amazon Web Services. He works with banks and insurance companies in Germany on machine learning. In his spare time, Mariano enjoys hiking with his wife.

Read More

Building out a machine learning operations (MLOps) platform in the rapidly evolving landscape of artificial intelligence (AI) and machine learning (ML) for organizations is essential for seamlessly bridging the gap between data science experimentation and deployment while meeting the requirements around model performance, security, and compliance.

In order to fulfill regulatory and compliance requirements, the key requirements when designing such a platform are:

• Address data drift
• Monitor model performance
• Facilitate automatic model retraining
• Provide a process for model approval
• Keep models in a secure environment

In this post, we show how to create an MLOps framework to address these needs while using a combination of AWS services and third-party toolsets. The solution entails a multi-environment setup with automated model retraining, batch inference, and monitoring with Amazon SageMaker Model Monitor, model versioning with SageMaker Model Registry, and a CI/CD pipeline to facilitate promotion of ML code and pipelines across environments by using Amazon SageMaker, Amazon EventBridge, Amazon Simple Notification Service (Amazon S3), HashiCorp Terraform, GitHub, and Jenkins CI/CD. We build a model to predict the severity (benign or malignant) of a mammographic mass lesion trained with the XGBoost algorithm using the publicly available UCI Mammography Mass dataset and deploy it using the MLOps framework. The full instructions with code are available in the GitHub repository.

Solution overview

The following architecture diagram shows an overview of the MLOps framework with the following key components:

• Multi account strategy – Two different environments (dev and prod) are set up in two different AWS accounts following the AWS Well-Architected best practices, and a third account is set up in the central model registry:
  • Dev environment – Where an Amazon SageMaker Studio domain is set up to allow model development, model training, and testing of ML pipelines (train and inference), before a model is ready to be promoted to higher environments.
  • Prod environment – Where the ML pipelines from dev are promoted to as a first step, and scheduled and monitored over time.
  • Central model registry – Amazon SageMaker Model Registry is set up in a separate AWS account to track model versions generated across the dev and prod environments.
• CI/CD and source control – The deployment of ML pipelines across environments is handled through CI/CD set up with Jenkins, along with version control handled through GitHub. Code changes merged to the corresponding environment git branch triggers a CI/CD workflow to make appropriate changes to the given target environment.
• Batch predictions with model monitoring – The inference pipeline built with Amazon SageMaker Pipelines runs on a scheduled basis to generate predictions along with model monitoring using SageMaker Model Monitor to detect data drift.
• Automated retraining mechanism – The training pipeline built with SageMaker Pipelines is triggered whenever a data drift is detected in the inference pipeline. After it’s trained, the model is registered into the central model registry to be approved by a model approver. When it’s approved, the updated model version is used to generate predictions through the inference pipeline.
• Infrastructure as code – The infrastructure as code (IaC), created using HashiCorp Terraform, supports the scheduling of the inference pipeline with EventBridge, triggering of the train pipeline based on an EventBridge rule and sending notifications using Amazon Simple Notification Service (Amazon SNS) topics.

The MLOps workflow includes the following steps:

1. Access the SageMaker Studio domain in the development account, clone the GitHub repository, go through the process of model development using the sample model provided, and generate the train and inference pipelines.
2. Run the train pipeline in the development account, which generates the model artifacts for the trained model version and registers the model into SageMaker Model Registry in the central model registry account.
3. Approve the model in SageMaker Model Registry in the central model registry account.
4. Push the code (train and inference pipelines, and the Terraform IaC code to create the EventBridge schedule, EventBridge rule, and SNS topic) into a feature branch of the GitHub repository. Create a pull request to merge the code into the main branch of the GitHub repository.
5. Trigger the Jenkins CI/CD pipeline, which is set up with the GitHub repository. The CI/CD pipeline deploys the code into the prod account to create the train and inference pipelines along with Terraform code to provision the EventBridge schedule, EventBridge rule, and SNS topic.
6. The inference pipeline is scheduled to run on a daily basis, whereas the train pipeline is set up to run whenever data drift is detected from the inference pipeline.
7. Notifications are sent through the SNS topic whenever there is a failure with either the train or inference pipeline.

Prerequisites

For this solution, you should have the following prerequisites:

• Three AWS accounts (dev, prod, and central model registry accounts)
• A SageMaker Studio domain set up in each of the three AWS accounts (see Onboard to Amazon SageMaker Studio or watch the video Onboard Quickly to Amazon SageMaker Studio for setup instructions)
• Jenkins (we use Jenkins 2.401.1) with administrative privileges installed on AWS
• Terraform version 1.5.5 or later installed on Jenkins server

For this post, we work in the us-east-1 Region to deploy the solution.

Provision KMS keys in dev and prod accounts

Our first step is to create AWS Key Management Service (AWS KMS) keys in the dev and prod accounts.

Create a KMS key in the dev account and give access to the prod account

Complete the following steps to create a KMS key in the dev account:

• On the AWS KMS console, choose Customer managed keys in the navigation pane.
• Choose Create key.
• For Key type, select Symmetric.
• For Key usage, select Encrypt and decrypt.
• Choose Next.

• Enter the production account number to give the production account access to the KMS key provisioned in the dev account. This is a required step because the first time the model is trained in the dev account, the model artifacts are encrypted with the KMS key before being written to the S3 bucket in the central model registry account. The production account needs access to the KMS key in order to decrypt the model artifacts and run the inference pipeline.
• Choose Next and finish creating your key.


After the key is provisioned, it should be visible on the AWS KMS console.

Create a KMS key in the prod account

Go through the same steps in the previous section to create a customer managed KMS key in the prod account. You can skip the step to share the KMS key to another account.

Set up a model artifacts S3 bucket in the central model registry account

Create an S3 bucket of your choice with the string sagemaker in the naming convention as part of the bucket’s name in the central model registry account, and update the bucket policy on the S3 bucket to give permissions from both the dev and prod accounts to read and write model artifacts into the S3 bucket.

The following code is the bucket policy to be updated on the S3 bucket:

{
    "Version": "2012-10-17",
    "Statement": [
        {
            "Sid": "AddPerm",
            "Effect": "Allow",
            "Principal": {
                "AWS": "arn:aws:iam::<dev-account-id>:root"
            },
            "Action": [
                "s3:PutObject",
                "s3:PutObjectAcl",
                "s3:GetObject",
                "s3:GetObjectVersion"
            ],
            "Resource": "arn:aws:s3:::<s3-bucket-in-central-model-registry-account>/*"
        },
        {
            "Sid": "AddPerm1",
            "Effect": "Allow",
            "Principal": {
                "AWS": "arn:aws:iam::<dev-account-id>:root"
            },
            "Action": "s3:ListBucket",
            "Resource": [
                "arn:aws:s3:::<s3-bucket-in-central-model-registry-account>",
                "arn:aws:s3:::<s3-bucket-in-central-model-registry-account>/*"
            ]
        },
        {
            "Sid": "AddPerm2",
            "Effect": "Allow",
            "Principal": {
                "AWS": "arn:aws:iam::<prod-account-id>:root"
            },
            "Action": [
                "s3:PutObject",
                "s3:PutObjectAcl",
                "s3:GetObject",
                "s3:GetObjectVersion"
            ],
            "Resource": "arn:aws:s3:::<s3-bucket-in-central-model-registry-account>/*"
        },
        {
            "Sid": "AddPerm3",
            "Effect": "Allow",
            "Principal": {
                "AWS": "arn:aws:iam::<prod-account-id>:root"
            },
            "Action": "s3:ListBucket",
            "Resource": [
                "arn:aws:s3:::<s3-bucket-in-central-model-registry-account>",
                "arn:aws:s3:::<s3-bucket-in-central-model-registry-account>/*"
            ]
        }
    ]
}

Set up IAM roles in your AWS accounts

The next step is to set up AWS Identity and Access Management (IAM) roles in your AWS accounts with permissions for AWS Lambda, SageMaker, and Jenkins.

Lambda execution role

Set up Lambda execution roles in the dev and prod accounts, which will be used by the Lambda function run as part of the SageMaker Pipelines Lambda step. This step will run from the inference pipeline to fetch the latest approved model, using which inferences are generated. Create IAM roles in the dev and prod accounts with the naming convention arn:aws:iam::<account-id>:role/lambda-sagemaker-role and attach the following IAM policies:

• Policy 1 – Create an inline policy named cross-account-model-registry-access, which gives access to the model package set up in the model registry in the central account:

  {
      "Version": "2012-10-17",
      "Statement": [
          {
              "Sid": "VisualEditor0",
              "Effect": "Allow",
              "Action": "sagemaker:ListModelPackages",
              "Resource": "arn:aws:sagemaker:us-east-1:<central-model-registry-account-id>:model-package/mammo-severity-model-package/*"
          },
          {
              "Sid": "VisualEditor1",
              "Effect": "Allow",
              "Action": "sagemaker:DescribeModelPackageGroup",
              "Resource": "arn:aws:sagemaker:us-east-1:<central-model-registry-account-id>:model-package-group/mammo-severity-model-package"
          }
      ]
  }

• Policy 2 – Attach AmazonSageMakerFullAccess, which is an AWS managed policy that grants full access to SageMaker. It also provides select access to related services, such as AWS Application Auto Scaling, Amazon S3, Amazon Elastic Container Registry (Amazon ECR), and Amazon CloudWatch Logs.
• Policy 3 – Attach AWSLambda_FullAccess, which is an AWS managed policy that grants full access to Lambda, Lambda console features, and other related AWS services.
• Policy 4 – Use the following IAM trust policy for the IAM role:

  {
      "Version": "2012-10-17",
      "Statement": [
          {
              "Effect": "Allow",
              "Principal": {
                  "Service": [
                      "lambda.amazonaws.com",
                      "sagemaker.amazonaws.com"
                  ]
              },
              "Action": "sts:AssumeRole"
          }
      ]
  }


SageMaker execution role

The SageMaker Studio domains set up in the dev and prod accounts should each have an execution role associated, which can be found on the Domain settings tab on the domain details page, as shown in the following screenshot. This role is used to run training jobs, processing jobs, and more within the SageMaker Studio domain.

Add the following policies to the SageMaker execution role in both accounts:

• Policy 1 – Create an inline policy named cross-account-model-artifacts-s3-bucket-access, which gives access to the S3 bucket in the central model registry account, which stores the model artifacts:

  {
      "Version": "2012-10-17",
      "Statement": [
          {
              "Sid": "VisualEditor0",
              "Effect": "Allow",
              "Action": [
                  "s3:PutObject",
                  "s3:GetObject",
                  "s3:GetObjectVersion"
              ],
              "Resource": "arn:aws:s3:::<s3-bucket-in-central-model-registry-account>/*"
          },
          {
              "Sid": "VisualEditor1",
              "Effect": "Allow",
              "Action": [
                  "s3:ListBucket"
              ],
              "Resource": [
                  "arn:aws:s3:::<s3-bucket-in-central-model-registry-account>",
                  "arn:aws:s3:::<s3-bucket-in-central-model-registry-account>/*"
              ]
          }
      ]
  }


• Policy 2 – Create an inline policy named cross-account-model-registry-access, which gives access to the model package in the model registry in the central model registry account:

  {
      "Version": "2012-10-17",
      "Statement": [
          {
              "Sid": "VisualEditor0",
              "Effect": "Allow",
              "Action": "sagemaker:CreateModelPackageGroup",
              "Resource": "arn:aws:sagemaker:us-east-1:<central-model-registry-account-id>:model-package-group/mammo-severity-model-package"
          }
      ]
  }


• Policy 3 – Create an inline policy named kms-key-access-policy, which gives access to the KMS key created in the previous step. Provide the account ID in which the policy is being created and the KMS key ID created in that account.

  {
      "Version": "2012-10-17",
      "Statement": [
          {
              "Sid": "AllowUseOfKeyInThisAccount",
              "Effect": "Allow",
              "Action": [
                  "kms:Encrypt",
                  "kms:Decrypt",
                  "kms:ReEncrypt*",
                  "kms:GenerateDataKey*",
                  "kms:DescribeKey"
              ],
              "Resource": "arn:aws:kms:us-east-1:<account-id>:key/<kms-key-id>"
          }
      ]
  }


• Policy 4 – Attach AmazonSageMakerFullAccess, which is an AWS managed policy that grants full access to SageMaker and select access to related services.
• Policy 5 – Attach AWSLambda_FullAccess, which is an AWS managed policy that grants full access to Lambda, Lambda console features, and other related AWS services.
• Policy 6 – Attach CloudWatchEventsFullAccess, which is an AWS managed policy that grants full access to CloudWatch Events.
• Policy 7 – Add the following IAM trust policy for the SageMaker execution IAM role:

  {
      "Version": "2012-10-17",
      "Statement": [
          {
              "Effect": "Allow",
              "Principal": {
                  "Service": [
                      "events.amazonaws.com",
                      "sagemaker.amazonaws.com"
                  ]
              },
              "Action": "sts:AssumeRole"
          }
      ]
  }


• Policy 8 (specific to the SageMaker execution role in the prod account) – Create an inline policy named cross-account-kms-key-access-policy, which gives access to the KMS key created in the dev account. This is required for the inference pipeline to read model artifacts stored in the central model registry account where the model artifacts are encrypted using the KMS key from the dev account when the first version of the model is created from the dev account.

  {
      "Version": "2012-10-17",
      "Statement": [
          {
              "Sid": "AllowUseOfKeyInDevAccount",
              "Effect": "Allow",
              "Action": [
                  "kms:Encrypt",
                  "kms:Decrypt",
                  "kms:ReEncrypt*",
                  "kms:GenerateDataKey*",
                  "kms:DescribeKey"
              ],
              "Resource": "arn:aws:kms:us-east-1:<dev-account-id>:key/<dev-kms-key-id>"
          }
      ]
  }


Cross-account Jenkins role

Set up an IAM role called cross-account-jenkins-role in the prod account, which Jenkins will assume to deploy ML pipelines and corresponding infrastructure into the prod account.

Add the following managed IAM policies to the role:

• CloudWatchFullAccess
• AmazonS3FullAccess
• AmazonSNSFullAccess
• AmazonSageMakerFullAccess
• AmazonEventBridgeFullAccess
• AWSLambda_FullAccess

Update the trust relationship on the role to give permissions to the AWS account hosting the Jenkins server:

{
    "Version": "2012-10-17",
    "Statement": [
        {
            "Effect": "Allow",
            "Principal": {
                "Service": "events.amazonaws.com",
                "AWS": "arn:aws:iam::<jenkins-account-id>:root"
            },
            "Action": "sts:AssumeRole",
            "Condition": {}
        }
    ]
}

Update permissions on the IAM role associated with the Jenkins server

Assuming that Jenkins has been set up on AWS, update the IAM role associated with Jenkins to add the following policies, which will give Jenkins access to deploy the resources into the prod account:

• Policy 1 – Create the following inline policy named assume-production-role-policy:

  {
      "Version": "2012-10-17",
      "Statement": [
          {
              "Sid": "VisualEditor0",
              "Effect": "Allow",
              "Action": "sts:AssumeRole",
              "Resource": "arn:aws:iam::<prod-account-id>:role/cross-account-jenkins-role"
          }
      ]
  }


• Policy 2 – Attach the CloudWatchFullAccess managed IAM policy.

Set up the model package group in the central model registry account

From the SageMaker Studio domain in the central model registry account, create a model package group called mammo-severity-model-package using the following code snippet (which you can run using a Jupyter notebook):

import boto3

model_package_group_name = "mammo-severity-model-package"
sm_client = boto3.Session().client("sagemaker")

create_model_package_group_response = sm_client.create_model_package_group(
    ModelPackageGroupName=model_package_group_name,
    ModelPackageGroupDescription="Cross account model package group for mammo severity model",

)

print('ModelPackageGroup Arn : {}'.format(create_model_package_group_response['ModelPackageGroupArn']))

Set up access to the model package for IAM roles in the dev and prod accounts

Provision access to the SageMaker execution roles created in the dev and prod accounts so you can register model versions within the model package mammo-severity-model-package in the central model registry from both accounts. From the SageMaker Studio domain in the central model registry account, run the following code in a Jupyter notebook:

import json
import boto3

model_package_group_name = "mammo-severity-model-package"
# Convert the policy from JSON dict to string
model_package_group_policy = dict(
{
  "Version": "2012-10-17",
  "Statement": [
    {
      "Sid": "AddPermModelPackageGroupCrossAccount",
      "Effect": "Allow",
      "Principal": {
        "AWS": ["arn:aws:iam::<dev-account-id>:root", "arn:aws:iam::<prod-account-id>:root"]
      },
      "Action": [
        "sagemaker:DescribeModelPackageGroup"
        ],
      "Resource": "arn:aws:sagemaker:us-east-1:<central-model-registry-account>:model-package-group/mammo-severity-model-package"
    },
    {
      "Sid": "AddPermModelPackageVersionCrossAccount",
      "Effect": "Allow",
      "Principal": {
        "AWS": ["arn:aws:iam::<dev-account-id>:root", "arn:aws:iam::<prod-account-id>:root"]
      },
      "Action": [
        "sagemaker:DescribeModelPackage",
        "sagemaker:ListModelPackages",
        "sagemaker:UpdateModelPackage",
        "sagemaker:CreateModelPackage",
        "sagemaker:CreateModel"
      ],
      "Resource": "arn:aws:sagemaker:us-east-1:<central-model-registry-account>:model-package/mammo-severity-model-package/*"
    }
  ]
})
model_package_group_policy = json.dumps(model_package_group_policy)
# Add Policy to the model package group
sm_client = boto3.Session().client("sagemaker")
response = sm_client.put_model_package_group_policy(
    ModelPackageGroupName = model_package_group_name,
    ResourcePolicy = model_package_group_policy)

Set up Jenkins

In this section, we configure Jenkins to create the ML pipelines and the corresponding Terraform infrastructure in the prod account through the Jenkins CI/CD pipeline.

• On the CloudWatch console, create a log group named jenkins-log within the prod account to which Jenkins will push logs from the CI/CD pipeline. The log group should be created in the same Region as where the Jenkins server is set up.

• Install the following plugins on your Jenkins server:
  1. Job DSL
  2. Git
  3. Pipeline
  4. Pipeline: AWS Steps
  5. Pipeline Utility Steps
• Set up AWS credentials in Jenkins using the cross-account IAM role (cross-account-jenkins-role) provisioned in the prod account.

• For System Configuration, choose AWS.

• Provide the credentials and CloudWatch log group you created earlier.

• Set up GitHub credentials within Jenkins.

• Create a new project in Jenkins.
• Enter a project name and choose Pipeline.

• On the General tab, select GitHub project and enter the forked GitHub repository URL.
• Select This project is parameterized.
• On the Add Parameter menu, choose String Parameter.

• For Name, enter prodAccount.
• For Default Value, enter the prod account ID.

• Under Advanced Project Options, for Definition, select Pipeline script from SCM.
• For SCM, choose Git.

• For Repository URL, enter the forked GitHub repository URL.
• For Credentials, enter the GitHub credentials saved in Jenkins.
• Enter main in the Branches to build section, based on which the CI/CD pipeline will be triggered.

• For Script Path, enter Jenkinsfile.
• Choose Save.


The Jenkins pipeline should be created and visible on your dashboard.

Provision S3 buckets, collect and prepare data

Complete the following steps to set up your S3 buckets and data:

• Create an S3 bucket of your choice with the string sagemaker in the naming convention as part of the bucket’s name in both dev and prod accounts to store datasets and model artifacts.
• Set up an S3 bucket to maintain the Terraform state in the prod account.
• Download and save the publicly available UCI Mammography Mass dataset to the S3 bucket you created earlier in the dev account.
• Fork and clone the GitHub repository within the SageMaker Studio domain in the dev account. The repo has the following folder structure:
  • /environments – Configuration script for prod environment
  • /mlops-infra – Code for deploying AWS services using Terraform code
  • /pipelines – Code for SageMaker pipeline components
  • Jenkinsfile – Script to deploy through Jenkins CI/CD pipeline
  • setup.py – Needed to install the required Python modules and create the run-pipeline command
  • mammography-severity-modeling.ipynb – Allows you to create and run the ML workflow
• Create a folder called data within the cloned GitHub repository folder and save a copy of the publicly available UCI Mammography Mass dataset.
• Follow the Jupyter notebook mammography-severity-modeling.ipynb.
• Run the following code in the notebook to preprocess the dataset and upload it to the S3 bucket in the dev account:

  import boto3
  import sagemaker
  import numpy as np
  import pandas as pd
  from sklearn.compose import ColumnTransformer
  from sklearn.impute import SimpleImputer
  from sklearn.pipeline import Pipeline
  from sklearn.preprocessing import StandardScaler, OneHotEncoder

  #Replace the values based on the resoures created
  default_bucket = "<s3-bucket-in-dev-account>"
  model_artifacts_bucket = "<s3-bucket-in-central-model-registry-account>"
  region = "us-east-1"
  model_name = "mammography-severity-model"
  role = sagemaker.get_execution_role()
  lambda_role = "arn:aws:iam::<dev-account-id>:role/lambda-sagemaker-role"
  kms_key = "arn:aws:kms:us-east-1:<dev-account-id>:key/<kms-key-id-in-dev-account>"
  model_package_group_name="arn:aws:sagemaker:us-east-1:<central-model-registry-account-id>:model-package-group/mammo-severity-model-package"

  feature_columns_names = [
      'BIRADS',
      'Age',
      'Shape',
      'Margin',
      'Density',
  ]
  feature_columns_dtype = {
      'BIRADS': np.float64,
      'Age': np.float64,
      'Shape': np.float64,
      'Margin': np.float64,
      'Density': np.float64,
  }

  # read raw dataset
  mammographic_data = pd.read_csv("data/mammographic_masses.data",header=None)

  # split data into batch and raw datasets
  batch_df =mammographic_data.sample(frac=0.05,random_state=200)
  raw_df =mammographic_data.drop(batch_df.index)

  # Split the raw datasets to two parts, one of which will be used to train
  #the model initially and then other dataset will be leveraged when
  #retraining the model
  train_dataset_part2 =raw_df.sample(frac=0.1,random_state=200)
  train_dataset_part1 =raw_df.drop(train_dataset_part2.index)

  # save the train datasets
  train_dataset_part1.to_csv("data/mammo-train-dataset-part1.csv",index=False)
  train_dataset_part2.to_csv("data/mammo-train-dataset-part2.csv",index=False)

  # remove label column from the batch dataset which will be used to generate inferences
  batch_df.drop(5,axis=1,inplace=True)

  # create a copy of the batch dataset
  batch_modified_df = batch_df

  def preprocess_batch_data(feature_columns_names,feature_columns_dtype,batch_df):
      batch_df.replace("?", "NaN", inplace = True)
      batch_df.columns = feature_columns_names
      batch_df = batch_df.astype(feature_columns_dtype)
      numeric_transformer = Pipeline(
          steps=[("imputer", SimpleImputer(strategy="median"))]
          )
      numeric_features = list(feature_columns_names)
      preprocess = ColumnTransformer(
          transformers=[
              ("num", numeric_transformer, numeric_features)
          ]
      )
      batch_df = preprocess.fit_transform(batch_df)
      return batch_df

  # save the batch dataset file
  batch_df = preprocess_batch_data(feature_columns_names,feature_columns_dtype,batch_df)
  pd.DataFrame(batch_df).to_csv("data/mammo-batch-dataset.csv", header=False, index=False)

  # modify batch dataset to introduce missing values
  batch_modified_df.replace("?", "NaN", inplace = True)
  batch_modified_df.columns = feature_columns_names
  batch_modified_df = batch_modified_df.astype(feature_columns_dtype)

  # save the batch dataset with outliers file
  batch_modified_df.to_csv("data/mammo-batch-dataset-outliers.csv",index=False)


The code will generate the following datasets:

• • data/ mammo-train-dataset-part1.csv – Will be used to train the first version of model.
  • data/ mammo-train-dataset-part2.csv  – Will be used to train the second version of model along with the mammo-train-dataset-part1.csv dataset.
  • data/mammo-batch-dataset.csv – Will be used to generate inferences.
  • data/mammo-batch-dataset-outliers.csv – Will introduce outliers into the dataset to fail the inference pipeline. This will enable us to test the pattern to trigger automated retraining of the model.
• Upload the dataset mammo-train-dataset-part1.csv under the prefix mammography-severity-model/train-dataset, and upload the datasets mammo-batch-dataset.csv and mammo-batch-dataset-outliers.csv to the prefix mammography-severity-model/batch-dataset of the S3 bucket created in the dev account:

  import boto3
  s3_client = boto3.resource('s3')
  s3_client.Bucket(default_bucket).upload_file("data/mammo-train-dataset-part1.csv","mammography-severity-model/data/train-dataset/mammo-train-dataset-part1.csv")
  s3_client.Bucket(default_bucket).upload_file("data/mammo-batch-dataset.csv","mammography-severity-model/data/batch-dataset/mammo-batch-dataset.csv")
  s3_client.Bucket(default_bucket).upload_file("data/mammo-batch-dataset-outliers.csv","mammography-severity-model/data/batch-dataset/mammo-batch-dataset-outliers.csv")


• Upload the datasets mammo-train-dataset-part1.csv and mammo-train-dataset-part2.csv under the prefix mammography-severity-model/train-dataset into the S3 bucket created in the prod account through the Amazon S3 console.

• Upload the datasets mammo-batch-dataset.csv and mammo-batch-dataset-outliers.csv to the prefix mammography-severity-model/batch-dataset of the S3 bucket in the prod account.


Run the train pipeline

Under <project-name>/pipelines/train, you can see the following Python scripts:

• scripts/raw_preprocess.py – Integrates with SageMaker Processing for feature engineering
• scripts/evaluate_model.py – Allows model metrics calculation, in this case auc_score
• train_pipeline.py – Contains the code for the model training pipeline

Complete the following steps:

• Upload the scripts into Amazon S3:

  import boto3
  s3_client = boto3.resource('s3')
  s3_client.Bucket(default_bucket).upload_file("pipelines/train/scripts/raw_preprocess.py","mammography-severity-model/scripts/raw_preprocess.py")
  s3_client.Bucket(default_bucket).upload_file("pipelines/train/scripts/evaluate_model.py","mammography-severity-model/scripts/evaluate_model.py")

• Get the train pipeline instance:

  from pipelines.train.train_pipeline import get_pipeline

  train_pipeline = get_pipeline(
                          region=region,
                          role=role,
                          default_bucket=default_bucket,
                          model_artifacts_bucket=model_artifacts_bucket,
                          model_name = model_name,
                          kms_key = kms_key,
                          model_package_group_name= model_package_group_name,
                          pipeline_name="mammo-severity-train-pipeline",
                          base_job_prefix="mammo-severity",
                      )

  train_pipeline.definition()


• Submit the train pipeline and run it:

  train_pipeline.upsert(role_arn=role)
  train_execution = train_pipeline.start()


The following figure shows a successful run of the training pipeline. The final step in the pipeline registers the model in the central model registry account.

Approve the model in the central model registry

Log in to the central model registry account and access the SageMaker model registry within the SageMaker Studio domain. Change the model version status to Approved.

Once approved, the status should be changed on the model version.

Run the inference pipeline (Optional)

This step is not required but you can still run the inference pipeline to generate predictions in the dev account.

Under <project-name>/pipelines/inference, you can see the following Python scripts:

• scripts/lambda_helper.py – Pulls the latest approved model version from the central model registry account using a SageMaker Pipelines Lambda step
• inference_pipeline.py – Contains the code for the model inference pipeline

Complete the following steps:

• Upload the script to the S3 bucket:

  import boto3
  s3_client = boto3.resource('s3')
  s3_client.Bucket(default_bucket).upload_file("pipelines/inference/scripts/lambda_helper.py","mammography-severity-model/scripts/lambda_helper.py")


• Get the inference pipeline instance using the normal batch dataset:

  from pipelines.inference.inference_pipeline import get_pipeline

  inference_pipeline = get_pipeline(
                          region=region,
                          role=role,
                          lambda_role = lambda_role,
                          default_bucket=default_bucket,
                          kms_key=kms_key,
                          model_name = model_name,
                          model_package_group_name= model_package_group_name,
                          pipeline_name="mammo-severity-inference-pipeline",
                          batch_dataset_filename = "mammo-batch-dataset"
                      )


• Submit the inference pipeline and run it:

  inference_pipeline.upsert(role_arn=role)
  inference_execution = inference_pipeline.start()


The following figure shows a successful run of the inference pipeline. The final step in the pipeline generates the predictions and stores them in the S3 bucket. We use MonitorBatchTransformStep to monitor the inputs into the batch transform job. If there are any outliers, the inference pipeline goes into a failed state.

Run the Jenkins pipeline

The environment/ folder within the GitHub repository contains the configuration script for the prod account. Complete the following steps to trigger the Jenkins pipeline:

• Update the config script prod.tfvars.json based on the resources created in the previous steps:

  {
      "env_group": "prod",
      "aws_region": "us-east-1",
      "event_bus_name": "default",
      "pipelines_alert_topic_name": "mammography-model-notification",
      "email":"admin@org.com",
      "lambda_role":"arn:aws:iam::<prod-account-id>:role/lambda-sagemaker-role",
      "default_bucket":"<s3-bucket-in-prod-account>",
      "model_artifacts_bucket": "<s3-bucket-in-central-model-registry-account>",
      "kms_key": "arn:aws:kms:us-east-1:<prod-account-id>:key/<kms-key-id-in-prod-account>",
      "model_name": "mammography-severity-model",
      "model_package_group_name":"arn:aws:sagemaker:us-east-1:<central-model-registry-account-id>:model-package-group/mammo-severity-model-package",
      "train_pipeline_name":"mammo-severity-train-pipeline",
      "inference_pipeline_name":"mammo-severity-inference-pipeline",
      "batch_dataset_filename":"mammo-batch-dataset",
      "terraform_state_bucket":"<s3-bucket-terraform-state-in-prod-account>",
      "train_pipeline": {
              "name": "mammo-severity-train-pipeline",
              "arn": "arn:aws:sagemaker:us-east-1:<prod-account-id>:pipeline/mammo-severity-train-pipeline",
              "role_arn": "arn:aws:iam::<prod-account-id>:role/service-role/<sagemaker-execution-role-in-prod-account>"
          },
      "inference_pipeline": {
              "name": "mammo-severity-inference-pipeline",
              "arn": "arn:aws:sagemaker:us-east-1:<prod-account-id>:pipeline/mammo-severity-inference-pipeline",
              "cron_schedule": "cron(0 23 * * ? *)",
              "role_arn": "arn:aws:iam::<prod-account-id>:role/service-role/<sagemaker-execution-role-in-prod-account>"
          }

  }


• Once updated, push the code into the forked GitHub repository and merge the code into main branch.
• Go to the Jenkins UI, choose Build with Parameters, and trigger the CI/CD pipeline created in the previous steps.


When the build is complete and successful, you can log in to the prod account and see the train and inference pipelines within the SageMaker Studio domain.

Additionally, you will see three EventBridge rules on the EventBridge console in the prod account:

• Schedule the inference pipeline
• Send a failure notification on the train pipeline
• When the inference pipeline fails to trigger the train pipeline, send a notification

Finally, you will see an SNS notification topic on the Amazon SNS console that sends notifications through email. You’ll get an email asking you to confirm the acceptance of these notification emails.

Test the inference pipeline using a batch dataset without outliers

To test if the inference pipeline is working as expected in the prod account, we can log in to the prod account and trigger the inference pipeline using the batch dataset without outliers.

Run the pipeline via the SageMaker Pipelines console in the SageMaker Studio domain of the prod account, where the transform_input will be the S3 URI of the dataset without outliers (s3://<s3-bucket-in-prod-account>/mammography-severity-model/data/mammo-batch-dataset.csv).

The inference pipeline succeeds and writes the predictions back to the S3 bucket.

Test the inference pipeline using a batch dataset with outliers

You can run the inference pipeline using the batch dataset with outliers to check if the automated retraining mechanism works as expected.

Run the pipeline via the SageMaker Pipelines console in the SageMaker Studio domain of the prod account, where the transform_input will be the S3 URI of the dataset with outliers (s3://<s3-bucket-in-prod-account>/mammography-severity-model/data/mammo-batch-dataset-outliers.csv).

The inference pipeline fails as expected, which triggers the EventBridge rule, which in turn triggers the train pipeline.

After a few moments, you should see a new run of the train pipeline on the SageMaker Pipelines console, which picks up the two different train datasets (mammo-train-dataset-part1.csv and mammo-train-dataset-part2.csv) uploaded to the S3 bucket to retrain the model.

You will also see a notification sent to the email subscribed to the SNS topic.

To use the updated model version, log in to the central model registry account and approve the model version, which will be picked up during the next run of the inference pipeline triggered through the scheduled EventBridge rule.

Although the train and inference pipelines use a static dataset URL, you can have the dataset URL passed to the train and inference pipelines as dynamic variables in order to use updated datasets to retrain the model and generate predictions in a real-world scenario.

Clean up

To avoid incurring future charges, complete the following steps:

• Remove the SageMaker Studio domain across all the AWS accounts.
• Delete all the resources created outside SageMaker, including the S3 buckets, IAM roles, EventBridge rules, and SNS topic set up through Terraform in the prod account.
• Delete the SageMaker pipelines created across accounts using the AWS Command Line Interface (AWS CLI).

Conclusion

Organizations often need to align with enterprise-wide toolsets to enable collaboration across different functional areas and teams. This collaboration ensures that your MLOps platform can adapt to evolving business needs and accelerates the adoption of ML across teams. This post explained how to create an MLOps framework in a multi-environment setup to enable automated model retraining, batch inference, and monitoring with Amazon SageMaker Model Monitor, model versioning with SageMaker Model Registry, and promotion of ML code and pipelines across environments with a CI/CD pipeline. We showcased this solution using a combination of AWS services and third-party toolsets. For instructions on implementing this solution, see the GitHub repository. You can also extend this solution by bringing in your own data sources and modeling frameworks.

About the Authors

Gayatri Ghanakota is a Sr. Machine Learning Engineer with AWS Professional Services. She is passionate about developing, deploying, and explaining AI/ ML solutions across various domains. Prior to this role, she led multiple initiatives as a data scientist and ML engineer with top global firms in the financial and retail space. She holds a master’s degree in Computer Science specialized in Data Science from the University of Colorado, Boulder.

Sunita Koppar is a Sr. Data Lake Architect with AWS Professional Services. She is passionate about solving customer pain points processing big data and providing long-term scalable solutions. Prior to this role, she developed products in internet, telecom, and automotive domains, and has been an AWS customer. She holds a master’s degree in Data Science from the University of California, Riverside.

Saswata Dash is a DevOps Consultant with AWS Professional Services. She has worked with customers across healthcare and life sciences, aviation, and manufacturing. She is passionate about all things automation and has comprehensive experience in designing and building enterprise-scale customer solutions in AWS. Outside of work, she pursues her passion for photography and catching sunrises.

Read More

Generative AI models for coding companions are mostly trained on publicly available source code and natural language text. While the large size of the training corpus enables the models to generate code for commonly used functionality, these models are unaware of code in private repositories and the associated coding styles that are enforced when developing with them. Consequently, the generated suggestions may require rewriting before they are appropriate for incorporation into an internal repository.

We can address this gap and minimize additional manual editing by embedding code knowledge from private repositories on top of a language model trained on public code. This is why we developed a customization capability for Amazon CodeWhisperer. In this post, we show you two possible ways of customizing coding companions using retrieval augmented generation and fine-tuning.

Our goal with CodeWhisperer customization capability is to enable organizations to tailor the CodeWhisperer model using their private repositories and libraries to generate organization-specific code recommendations that save time, follow organizational style and conventions, and avoid bugs or security vulnerabilities. This benefits enterprise software development and helps overcome the following challenges:

1. Sparse documentation or information for internal libraries and APIs that forces developers to spend time examining previously written code to replicate usage.
2. Lack of awareness and consistency in implementing enterprise-specific coding practices, styles and patterns.
3. Inadvertent use of deprecated code and APIs by developers.

By using internal code repositories for additional training that have already undergone code reviews, the language model can surface the use of internal APIs and code blocks that overcome the preceding list of problems. Because the reference code is already reviewed and meets the customer’s high bar, the likelihood of introducing bugs or security vulnerabilities is also minimized. And, by carefully selecting of the source files used for customization, organizations can reduce the use of deprecated code.

Design challenges

Customizing code suggestions based on an organization’s private repositories has many interesting design challenges. Deploying large language models (LLMs) to surface code suggestions has fixed costs for availability and variable costs due to inference based on the number of tokens generated. Therefore, having separate customizations for each customer and hosting them individually, thereby incurring additional fixed costs, can be prohibitively expensive. On the other hand, having multiple customizations simultaneously on the same system necessitates multi-tenant infrastructure to isolate proprietary code for each customer. Furthermore, the customization capability should surface knobs to enable the selection of the appropriate training subset from the internal repository using different metrics (for example, files with a history of fewer bugs or code that is recently committed into the repository). By selecting the code based on these metrics, the customization can be trained using higher-quality code which can improve the quality of code suggestions. Finally, even with continuously evolving code repositories, the cost associated with customization should be minimal to help enterprises realize cost savings from increased developer productivity.

A baseline approach to building customization could be to pretrain the model on a single training corpus composed of of the existing (public) pretraining dataset along with the (private) enterprise code. While this approach works in practice, it requires (redundant) individual pretraining using the public dataset for each enterprise. It also requires redundant deployment costs associated with hosting a customized model for each customer that only serves client requests originating from that customer. By decoupling the training of public and private code and deploying the customization on a multi-tenant system, these redundant costs can be avoided.

How to customize

At a high level, there are two types of possible customization techniques: retrieval-augmented generation (RAG) and fine-tuning (FT).

• Retrieval-augmented generation: RAG finds matching pieces of code within a repository that is similar to a given code fragment (for example, code that immediately precedes the cursor in the IDE) and augments the prompt used to query the LLM with these matched code snippets. This enriches the prompt to help nudge the model into generating more relevant code. There are a few techniques explored in the literature along these lines. See Retrieval-Augmented Generation for Knowledge-Intensive NLP Tasks, REALM, kNN-LM and RETRO.

• Fine-tuning: FT takes a pre-trained LLM and trains it further on a specific, smaller codebase (compared to the pretraining dataset) to adapt it for the appropriate repository. Fine-tuning adjusts the LLM’s weights based on this training, making it more tailored to the organization’s unique needs.

Both RAG and fine-tuning are powerful tools for enhancing the performance of LLM-based customization. RAG can quickly adapt to private libraries or APIs with lower training complexity and cost. However, searching and augmenting retrieved code snippets to the prompt increases latency at runtime. Instead, fine-tuning does not require any augmentation of the context because the model is already trained on private libraries and APIs. However, it leads to higher training costs and complexities in serving the model, when multiple custom models have to be supported across multiple enterprise customers. As we discuss later, these concerns can be remedied by optimizing the approach further.

Retrieval augmented generation

There are a few steps involved in RAG:

Indexing

Given a private repository as input by the admin, an index is created by splitting the source code files into chunks. Put simply, chunking turns the code snippets into digestible pieces that are likely to be most informative for the model and are easy to retrieve given the context. The size of a chunk and how it is extracted from a file are design choices that affect the final result. For example, chunks can be split based on lines of code or based on syntactic blocks, and so on.

Administrator Workflow

Contextual search

Search a set of indexed code snippets based on a few lines of code above the cursor and retrieve relevant code snippets. This retrieval can happen using different algorithms. These choices might include:

• Bag of words (BM25) – A bag-of-words retrieval function that ranks a set of code snippets based on the query term frequencies and code snippet lengths.

BM25-based retrieval

The following figure illustrates how BM25 works. In order to use BM25, an inverted index is built first. This is a data structure that maps different terms to the code snippets that those terms occur in. At search time, we look up code snippets based on the terms present in the query and score them based on the frequency.

• Semantic retrieval [Contriever, UniXcoder] – Converts query and indexed code snippets into high-dimensional vectors and ranks code snippets based on semantic similarity. Formally, often k-nearest neighbors (KNN) or approximate nearest neighbor (ANN) search is often used to find other snippets with similar semantics.

Semantic retrieval

BM25 focuses on lexical matching. Therefore, replacing “add” with “delete” may not change the BM25 score based on the terms in the query, but the retrieved functionality may be the opposite of what is required. In contrast, semantic retrieval focuses on the functionality of the code snippet even though variable and API names may be different. Typically, a combination of BM25 and semantic retrievals can work well together to deliver better results.

Augmented inference

When developers write code, their existing program is used to formulate a query that is sent to the retrieval index. After retrieving multiple code snippets using one of the techniques discussed above, we prepend them to the original prompt. There are many design choices here, including the number of snippets to be retrieved, the relative placement of the snippets in the prompt, and the size of the snippet. The final design choice is primarily driven by empirical observation by exploring various approaches with the underlying language model and plays a key role in determining the accuracy of the approach. The contents from the returned chunks and the original code are combined and sent to the model to get customized code suggestions.

Developer workflow

Fine tuning:

Fine-tuning a language model is done for transfer learning in which the weights of a pre-trained model are trained on new data. The goal is to retain the appropriate knowledge from a model already trained on a large corpus and refine, replace, or add new knowledge from the new corpus — in our case, a new codebase. Simply training on a new codebase leads to catastrophic forgetting. For example, the language model may “forget” its knowledge of safety or the APIs that are sparsely used in the enterprise codebase to date. There are a variety of techniques like experience replay, GEM, and PP-TF that are employed to address this challenge.

Fine tuning

There are two ways of fine-tuning. One approach is to use the additional data without augmenting the prompt to fine-tune the model. Another approach is to augment the prompt during fine-tuning by retrieving relevant code suggestions. This helps improve the model’s ability to provide better suggestions in the presence of retrieved code snippets. The model is then evaluated on a held-out set of examples after it is trained. Subsequently, the customized model is deployed and used for generating the code suggestions.

Despite the advantages of using dedicated LLMs for generating code on private repositories, the costs can be prohibitive for small and medium-sized organizations. This is because dedicated compute resources are necessary even though they may be underutilized given the size of the teams. One way to achieve cost efficiency is serving multiple models on the same compute (for example, SageMaker multi-tenancy). However, language models require one or more dedicated GPUs across multiple zones to handle latency and throughput constraints. Hence, multi-tenancy of full model hosting on each GPU is infeasible.

We can overcome this problem by serving multiple customers on the same compute by using small adapters to the LLM. Parameter-efficient fine-tuning (PEFT) techniques like prompt tuning, prefix tuning, and Low-Rank Adaptation (LoRA) are used to lower training costs without any loss of accuracy. LoRA, especially, has seen great success at achieving similar (or better) accuracy than full-model fine-tuning. The basic idea is to design a low-rank matrix that is then added to the matrices with the original matrix weight of targeted layers of the model. Typically, these adapters are then merged with the original model weights for serving. This leads to the same size and architecture as the original neural network. Keeping the adapters separate, we can serve the same base model with many model adapters. This brings the economies of scale back to our small and medium-sized customers.

Low-Rank Adaptation (LoRA)

Measuring effectiveness of customization

We need evaluation metrics to assess the efficacy of the customized solution. Offline evaluation metrics act as guardrails against shipping customizations that are subpar compared to the default model. By building datasets out of a held-out dataset from within the provided repository, the customization approach can be applied to this dataset to measure effectiveness. Comparing the existing source code with the customized code suggestion quantifies the usefulness of the customization. Common measures used for this quantification include metrics like edit similarity, exact match, and CodeBLEU.

It is also possible to measure usefulness by quantifying how often internal APIs are invoked by the customization and comparing it with the invocations in the pre-existing source. Of course, getting both aspects right is important for a successful completion. For our customization approach, we have designed a tailor-made metric known as Customization Quality Index (CQI), a single user-friendly measure ranging between 1 and 10. The CQI metric shows the usefulness of the suggestions from the customized model compared to code suggestions with a generic public model.

Summary

We built Amazon CodeWhisperer customization capability based on a mixture of the leading technical techniques discussed in this blog post and evaluated it with user studies on developer productivity, conducted by Persistent Systems. In these two studies, commissioned by AWS, developers were asked to create a medical software application in Java that required use of their internal libraries. In the first study, developers without access to CodeWhisperer took (on average) ~8.2 hours to complete the task, while those who used CodeWhisperer (without customization) completed the task 62 percent faster in (on average) ~3.1 hours.

In the second study with a different set of developer cohorts, developers using CodeWhisperer that had been customized using their private codebase completed the task in 2.5 hours on average, 28 percent faster than those who were using CodeWhisperer without customization and completed the task in ~3.5 hours on average. We strongly believe tools like CodeWhisperer that are customized to your codebase have a key role to play in further boosting developer productivity and recommend giving it a run. For more information and to get started, visit the Amazon CodeWhisperer page.

About the authors

Qing Sun is a Senior Applied Scientist in AWS AI Labs and work on AWS CodeWhisperer, a generative AI-powered coding assistant. Her research interests lie in Natural Language Processing, AI4Code and generative AI. In the past, she had worked on several NLP-based services such as Comprehend Medical, a medical diagnosis system at Amazon Health AI and Machine Translation system at Meta AI. She received her PhD from Virginia Tech in 2017.

Arash Farahani is an Applied Scientist with Amazon CodeWhisperer. His current interests are in generative AI, search, and personalization. Arash is passionate about building solutions that resolve developer pain points. He has worked on multiple features within CodeWhisperer, and introduced NLP solutions into various internal workstreams that touch all Amazon developers. He received his PhD from University of Illinois at Urbana-Champaign in 2017.

Xiaofei Ma is an Applied Science Manager in AWS AI Labs. He joined Amazon in 2016 as an Applied Scientist within SCOT organization and then later AWS AI Labs in 2018 working on Amazon Kendra. Xiaofei has been serving as the science manager for several services including Kendra, Contact Lens, and most recently CodeWhisperer and CodeGuru Security. His research interests lie in the area of AI4Code and Natural Language Processing. He received his PhD from University of Maryland, College Park in 2010.

Murali Krishna Ramanathan is a Principal Applied Scientist in AWS AI Labs and co-leads AWS CodeWhisperer, a generative AI-powered coding companion. He is passionate about building software tools and workflows that help improve developer productivity. In the past, he built Piranha, an automated refactoring tool to delete code due to stale feature flags and led code quality initiatives at Uber engineering. He is a recipient of the Google faculty award (2015), ACM SIGSOFT Distinguished paper award (ISSTA 2016) and Maurice Halstead award (Purdue 2006). He received his PhD in Computer Science from Purdue University in 2008.

Ramesh Nallapati is a Senior Principal Applied Scientist in AWS AI Labs and co-leads CodeWhisperer, a generative AI-powered coding companion, and Titan Large Language Models at AWS. His interests are mainly in the areas of Natural Language Processing and Generative AI. In the past, Ramesh has provided science leadership in delivering many NLP-based AWS products such as Kendra, Quicksight Q and Contact Lens. He held research positions at Stanford, CMU and IBM Research, and received his Ph.D. in Computer Science from University of Massachusetts Amherst in 2006.

Read More
